SolaX Power X3-ULTRA Series User Manual

102
Operation on LCD
Setting External ATS
External ATS function is used to achieve automatic switching from grid connection mode
to off grid mode or from off grid mode to grid connection model by using external ATS
equipment. The function is disabled by default. When the X3-PBOX-150K G2 is connected
in the parallel system, please enable the function.
• Enable: on/off-grid switching by external equipment.
• Disable: inverter internal on/off-grid switching.
=====External ATS=====
Function Control
> Disable <
Setting Power Factor
The default value is the specified value under the current safety regulations. The contents
will be displayed according to the requirements of local laws and regulations. Please refer
to local grid requirements.
====Power Factor====
>Mode Select
> off <
====Power Factor====
>Mode Select
> Over Excited <
====Power Factor====
>Mode Select
> Under Excited <
====Power Factor====
>Mode Select
> Curve <
====Power Factor====
>Mode Select
> Q(u) <
====Power Factor====
>Mode Select
> Fixed Q Power <
Off
Over Excited PF Value
Under Excited PF Value
Curve
P1 PF
P2 PF
P3 PF
P4 PF
Power 1
Power 2
Power 3
Power 4
PflockInPoint
