Levelogger Series User Guide
Page 11
Levelogger Edge Technical Specifications
Level Sensor: Piezoresistive Silicon with Hastelloy Sensor
Ranges: 5, 10, 20, 30, 100, 200 m
Accuracy: ± 0.05% FS
Resolution: 0.001% FS to 0.0006% FS
Normalization: Automatic Temperature Compensation
Temp. Comp. Range: 0ºC to 50ºC
Temperature Sensor: Platinum Resistance Temperature Detector (RTD)
Temp. Sensor Accuracy: ± 0.05ºC
Temp. Sensor Resolution: 0.003ºC
Battery Life: 10 years (based on 1 reading/minute)
Clock Accuracy (typical): ± 1 minute/year (-20ºC to 80ºC)
Operating Temperature: -20ºC to 80ºC
Maximum # Readings: 40,000 sets of readings
Memory: Continuous or Slate mode
Communication Speed: 9600 bps, 38,400 bps with USB optical reader
Com Interface: Optical Infra-red: USB, RS-232, SDI-12
Size: 22 mm x 159 mm (7/8" x 6.25")
Weight: 129 grams (4.5 oz.)
Corrosion Resistance:
Titanium based PVD coated body and superior corrosion resistant
Hastelloy sensor
Other Wetted Materials: Delrin, Viton, 316L Stainless Steel
Sampling Modes:
Linear, Event & User-Selectable Schedule with Repeat Mode,
Future Start, Future Stop, Real Time View
Measurement Rates: 0.125 second to 99 hours
Barometric Compensation: High accuracy, air-only, Barologger Edge
1.1.6 Levelogger Edge
The Levelogger Edge is an absolute (non-vented) datalogger, which measures groundwater and surface water
levels and temperature. Water levels are displayed as temperature compensated pressure readings, and can
be barometrically compensated with the aid of a Barologger.
Note: Solinst recommends using the most recent Levelogger Edge firmware version with the latest Levelogger
Software version. See Section 2.3.
Models Full Scale Accuracy Resolution
M5 5 m (16.4 ft.) ± 0.3 cm (0.010 ft.) 0.001% FS
M10 10 m (32.8 ft.) ± 0.5 cm (0.016 ft.) 0.0006% FS
M20 20 m (65.6 ft.) ± 1 cm (0.032 ft.) 0.0006% FS
M30 30 m (98.4 ft.) ± 1.5 cm (0.064 ft.) 0.0006% FS
M100 100 m (328.1 ft.) ± 5 cm (0.164 ft.) 0.0006% FS
M200 200 m (656.2 ft.) ± 10 cm (0.328 ft.) 0.0006% FS
For “5” series loggers, see “3001 5 Series Loggers.ai”
