Levelogger Series User Guide
Page 15
1.1.10 Rainlogger Edge
The Rainlogger Edge is designed for use with most standard tipping-bucket rain gauges. It records each tip
time from the tipping-bucket, and outputs the amount of rainfall per programmed time period (based on
rainfall calibration constant).
Note: Solinst recommends using the most recent Rainlogger Edge firmware version with the latest Levelogger
Software version. See Section 2.3.
Rainlogger Edge Technical Specifications
Battery Life: 10 years (logging 2 parameters/10 minutes)
Clock Accuracy (typical): ± 1 minute/year
Operating Temperature: -20˚C to 80˚C
Maximum # Readings: Up to 60,000 tip times
Memory: Continuous or Slate mode
Communication: Optical infra-red: USB, RS-232, SDI-12
Measurement:
Records each tip by the tipping-bucket rain gauge and outputs
the amount of rainfall
Sampling Mode: Event Based, Future Start, Real TIme View
Size: 22 mm x 140 mm (7/8" x 5.5")
Weight: 44 grams (1.6 oz)
Materials: ABS, Delrin®, Viton®
For “5” series loggers, see “3001 5 Series Loggers.ai”
