Levelogger Series User Guide
Page 14
1.1.9 LTC Levelogger Edge
The LTC Levelogger Edge provides an accurate and convenient method to measure water level, temperature
and conductivity all in one probe.
Note: Solinst recommends using the most recent LTC Levelogger Edge firmware version with the latest Levelogger
Software version. See Section 2.3.
LTC Levelogger Edge Technical Specifications
Level Sensor: Piezoresistive Silicon with Hastelloy Sensor
Ranges: 15, 10, 20, 30, 100, and 200 m
Accuracy: ± 0.05% FS
Resolution: 0.001% FS to 0.0006% FS
Normalization: Automatic Temperature Compensation
Temp Comp. Range: 0ºC to 50ºC
Temperature Sensor: Platinum Resistance Temperature Detector (RTD)
Accuracy: ± 0.05ºC
Resolution: 0.003ºC
Conductivity Sensor: 4-Electrode Platinum
Full Range: 0 to 100,000 µS/cm
Calibrated Range: 50 to 80,000 µS/cm
Accuracy:
±1% 5,000 µS/cm - 80,000 µS/cm; greater of ±2% or 10 µS/cm from
50 µS/cm - 5,000 µS/cm
Resolution: ± 0.1 µS/cm
Normalization: Specific Conductance normalized to 25ºC for full range
User Calibration Points: 1413, 5000, 12,880, 80,000 µS
Battery Life: 8 years (based on 1 reading every 5 minutes)
Clock Accuracy (typical): ± 1 minute / year
Operating Temperature: -20ºC to 80ºC
Memory: Continuous or Slate Mode
Maximum # Readings: 27,000 sets of readings
Communication Speed: 9600 bps, 38,400 bps with USB optical reader
Com Interface: Optical Infrared: USB, RS-232, SDI-12
Size: 22 mm x 190 mm (7/8" x 7.5")
Weight: 200 g (7.05 oz.)
Corrosion Resistance:
Titanium ceramic PVD coated body and superior corrosion
resistant Hastelloy pressure sensor
Other Wetted Materials: Hastelloy, Delrin®, Viton®, Platinum
Sampling Mode:
Linear, Event & User-Selectable Schedule with Repeat Mode,
Future Start, Future Stop, Real Time View
Measurement Rates: 2 seconds to 99 hours
Barometric Compensation: High accuracy, air-only, Barologger
Models Full Scale Accuracy Resolution
M5 5 m (16.4 ft.) ± 0.3 cm (0.010 ft.) 0.001% FS
M10 10 m (32.8 ft.) ± 0.5 cm (0.016 ft.) 0.0006% FS
M20 20 m (65.6 ft.) ± 1 cm (0.032 ft.) 0.0006% FS
M30 30 m (98.4 ft.) ± 1.5 cm (0.064 ft.) 0.0006% FS
M100 100 m (328.1 ft.) ± 5 cm (0.164 ft.) 0.0006% FS
M200 200 m (656.2 ft.) ± 10 cm (0.328 ft.) 0.0006% FS
