Levelogger Series User Guide
Page 13
Levelogger Junior Edge Technical Specifications
Level Sensor: Piezoresistive Silicon with Hastelloy Sensor
Ranges: 5, 10 m
Accuracy: ± 0.1% FS
Resolution: 0.02% FS to 0.01% FS
Normalization: Automatic Temperature Compensation
Temp Comp. Range: 0ºC to 40ºC
Temperature Sensor: Platinum Resistance Temperature Detector (RTD)
Accuracy: ± 0.1ºC
Resolution: 0.1ºC
Battery life: 5 years (based on 1 reading/minute)
Clock Accuracy (typical): ± 1 minute / year (-20ºC to 80ºC)
Operating Temperature: -20ºC to 80ºC
Memory: Continuous or Slate mode
Maximum # Readings 40,000 sets of readings
Com Interface: Optical Infra-red: USB, RS-232, SDI-12
Communication Speed: 9600 bps
Size: 22 mm x 142 mm (7/8" x 5.6")
Weight:
119 grams (4.2 oz)
Wetted Materials: Delrin®, Viton®, 316L Stainless Steel, Hastelloy
Sampling Mode: Linear, Future Start, Real Time View
Measurement Rates: 0.5 seconds to 99 hours
Barometric Compensation: High accuracy, air-only, Barologger Edge
1.1.8 Levelogger Junior Edge
The Levelogger Junior Edge provides an inexpensive alternative for measuring groundwater and surface
water levels and temperature.
Note: Solinst recommends using the most recent Levelogger Junior Edge firmware version with the latest
Levelogger Software version. See Section 2.3.
Models Full Scale (FS) Accuracy Resolution
M5 5 m (16.4 ft.) ± 0.6 cm (0.020 ft.) 0.02% FS
M10 10 m (32.8 ft.) ± 1.0 cm (0.032 ft.) 0.01% FS
For “5” series loggers, see “3001 5 Series Loggers.ai”
