[Video Stream 3]
Sets settings related to video codec 3.
Item Sub-item setting
Factory
default
Description
[Codec 2]
[H.264] / [H.265] / [Off] [Off] Sets the codec of image 2.
[Size 2]
3840×2160 / 1920×1080 / 1280×720 /
640×360 / 512×270
1920×1080 Sets the picture size of image 2.
[Frame Rate 2]
For details about supported frame
rates, see “Setting the Video Codec for
Streaming.”
–
Displayed when [Codec 2] is not set to
[Off].
Sets the frame rate of image 2.
[I-Picture Mode 2]
[Time] / [Frame] [Time]
Displayed when [Codec 2] is not set to
[Off].
Sets the IDR-Frame insertion interval for
image 2 as a time or number of frames.
[I-Picture Interval
2]
1 / 2 / 3 / 4 / 5 s 1
Displayed when both [Codec 2] is not set
to [Off] and [I-Picture Mode 2] is set to
[Time].
Sets the IDR-Frame insertion interval for
H.264 and H.265 as a time.
[I-Picture Ratio 2] 15 to 300 frames 30
Displayed when both [Codec 2] is not set
to [Off] and [I-Picture Mode 2] is set to
[Frame].
Sets the IDR-Frame insertion interval for
H.264 and H.265 as a number of frames.
[Profile 2]
[H.264]: [high] / [main] / [baseline]
[H.265]: [main]
– Sets the H.264 or H.265 profile.
[Bit Rate
Compression
Mode 2]
[CBR] / [VBR] [VBR]
Displayed when [Codec 2] is not set to
[Off].
Sets the bit rate compression mode of
image 2.
[Bit Rate 2]
512 / 768 / 1000 / 2000 / 3000 / 4000 /
5000 / 6000 / 7000 / 8000 / 16000 /
24000 / 32000 / 50000 / 64000 / 80000
kbps
8000
Sets the bit rate target value when both
[Codec 2] is not set to [Off] and [Bit Rate
Compression Mode 2] is set to [CBR].
[Quality 2]
1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 / 9 / 10 6
Displayed when both [Codec 2] is not set
to [Off] and [Bit Rate Compression Mode
2] is set to [VBR].
Sets the H.264 or H.265 quality.
Item Sub-item setting
Factory
default
Description
[Codec 3] [JPEG] [JPEG]
Sets the codec of image
3.
[Size 3]
1280×720 / 640×360 1280×720
Sets the picture size of
image 3.
