Note
Configure the unit so that it meets the operating conditions for the functions you want to use, then enable the connection with an
RCP/MSU. If the operating conditions are adjusted after the connection is enabled, unintended behavior may occur.
Operation
panel
Functions of the unit Operating conditions
MASTER
BLACK
Adjusting the master black level
Enabled when the shooting mode is set to
[Custom].
[H/V Ratio] and [Crispening] settings are
enabled when [Paint/Look] – [Detail] –
[Manual Setting] is set to [On] in the
camera menu.
DETAIL
Turning the detail function on/off
Setting the detail level
Setting [H/V Ratio]
Setting [Crispening]
User Matrix
Turning the user matrix correction function on/off
Setting matrix correction values (R-G/R-B/G-R/G-
B/B-R/B-G)
Multi Matrix
Turning the multi matrix correction function on/off
Setting the hue and saturation of the color used for
multi matrix correction
Turning on/off the display function (Gate function)
that distinguishes between the areas corresponding
to the colors that are the target of multi matrix
correction.
Note
Configurable only when the camera and RCP/MSU
are connected in Bridge mode.
Knee
Turning the knee correction function on/off
Turning the auto knee function on/off
Setting the knee point and knee slope
BARS
Turning color bars on/off
Note
Configurable only when the camera and RCP/MSU are
connected in Bridge mode.
SHUTTER
Turning the shutter function on/off
Setting the shutter speed value
(Turning auto shutter on/off, setting angle shutter,
setting slow shutter, and setting ECS not supported.)
Note
The RCP shutter settings may not be displayed
depending on the configured shutter speed value.
The RCP shutter settings may not be displayed
correctly if the shutter cannot be operated from the
RCP.
When auto shutter is on, auto shutter will
continue to operate even if you turn the shutter
on/off or change the shutter speed value from
the RCP.
When the shutter is set to [Angle], turning the
shutter on/off or changing the shutter speed
setting from the RCP is not supported.
To Next Page
