Sony DNW-A220 - Sub LCD Menu Settings (625;50 System)

A-11
DNW-A220
DNW-A220P
A. Setting Check Sheet
For 625/50 System
The sub LCD menu and the setup menu can store the data for 525/60 and 625/50 systems independently.
Then fill out the check sheets for each system, selecting system using the setup menu ITEM-013: 525/625
SYSTEM SELECT.
525/60 system : Pages A-4 to A-10
625/50 system: Pages A-11 to A-18
The same check sheets are used for a player and recorder. So, some menu items can be ignored in the
check sheets because they are not displayed.
Some menu items may be added or changed depending on the ROM version. In this case, please write
down notes in the margin.
Sub LCD menu
Home page
ITEM Factory setting Setting
AUDIO SETTING BANK AU-1
TIME CODE READER AUTO
VITC VITCON
VIDEO INPUT SDI
Audio setting page
ITEM Factory setting AU-1 AU- 2 AU- 3 AU-4
AU SG OFF
AGC OFF
LIMITER OFF
AUDIO INPUT IN-1 SDI-1
AUDIO INPUT IN-2 SDI-2
AUDIO INPUT IN-3 SDI-3
AUDIO INPUT IN-4 SDI-4
MIX/SWAP CH-1 IN-1
CH-2 IN-2
CH-3 IN-3
CH-4 IN-4
EMPH OFF
DOLBY OFF
LINE OUT CH-1/2
MONITOR LEVEL FIX
MONITOR CH L CH-1
R CH-2
625/50 system
