6-8
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MS-54 PD-128
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
D005 8-719-158-49 DIODE MA8120-TX
D006 8-719-027-76 DIODE 1SS357-TPH3
< FUSE >
0 F001 1-576-406-11 FUSE, MICRO 1.4A/32V
0 F002 1-576-406-11 FUSE, MICRO 1.4A/32V
0 F003 1-576-406-11 FUSE, MICRO 1.4A/32V
0 F004 1-576-406-11 FUSE, MICRO 1.4A/32V
0 F005 1-576-406-11 FUSE, MICRO 1.4A/32V
< INDUCTOR >
FB001 1-414-228-11 INDUCTOR CHIP 0uH
FB002 1-414-228-11 INDUCTOR CHIP 0uH
< LINE FILTER >
LF001 1-411-957-11 FILTER, COMMON MODE
< TRANSISTOR >
Q001 8-729-047-68 TRANSISTOR SSM3K03FE (TPL3)
Q002 8-729-046-77 TRANSISTOR SI4963DY-T1
Q003 8-729-804-41 TRANSISTOR 2SB1122-ST-TD
Q004 8-729-037-74 TRANSISTOR UN9213J- (K8).SO
< RESISTOR >
R001 1-216-821-11 METAL CHIP 1K 5% 1/16W
R002 1-216-821-11 METAL CHIP 1K 5% 1/16W
R003 1-216-853-11 METAL CHIP 470K 5% 1/16W
R004 1-216-857-11 METAL CHIP 1M 5% 1/16W
R005 1-216-150-91 RES-CHIP 10 5% 1/8W
R006 1-216-821-11 METAL CHIP 1K 5% 1/16W
R007 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R009 1-216-864-11 METAL CHIP 0 5% 1/16W
PPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
A-7074-363-A PD-128 BOARD, COMPLETE
***********************
(Ref.No.:2, 000 Series)
< CAPACITOR >
C801 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C802 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C803 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C804 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C805 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C806 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C807 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C808 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C810 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C811 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C812 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C813 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C814 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C815 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C816 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C817 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C818 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C819 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C902 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C903 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C904 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C905 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C906 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C907 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C908 1-164-872-11 CERAMIC CHIP 82PF 5% 16V
C909 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C911 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C912 1-164-872-11 CERAMIC CHIP 82PF 5% 16V
C913 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C914 1-113-994-11 TANTAL. CHIP 6.8uF 20% 16V
C915 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C916 1-107-689-21 TANTAL. CHIP 1uF 20% 35V
C917 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C918 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
< CONNECTOR >
CN801 1-779-064-11 PIN, CONNECTOR (PC BOARD) 12P
CN802 1-785-283-21 PIN, CONNECTOR (PC BOARD) 14P
* CN901 1-774-261-11 CONNECTOR, FFC (ZIF) 24P
< DIODE >
D801 8-719-073-01 DIODE MA111- (K8).S0
D902 8-713-102-80 DIODE 1T369-01-T8A
D903 8-719-976-96 DIODE MA8047-H-TX
< INDUCTOR >
FB801 1-414-234-22 INDUCTOR CHIP 0uH
FB802 1-414-234-22 INDUCTOR CHIP 0uH
FB803 1-414-234-22 INDUCTOR CHIP 0uH
< IC >
IC801 8-759-364-05 IC MB40D001PFV-G-BND-ER
IC802 8-759-539-27 IC IR3Y37A4
IC901 8-759-587-61 IC LZ9GH234
IC902 8-759-327-01 IC NJM062V (TE2)
< COIL >
L801 1-414-757-11 INDUCTOR 10 0uH
L802 1-414-078-11 INDUCTOR 1 0uH
L803 1-412-947-11 INDUCTOR 4.7uH
L901 1-414-754-11 INDUCTOR 1 0uH
L902 1-414-754-11 INDUCTOR 1 0uH
L903 1-412-951-11 INDUCTOR 1 0uH
L905 1-412-949-21 INDUCTOR 6.8uH
< TRANSISTOR >
Q901 8-729-037-52 TRANSISTOR 2SD2216J-QR (K8).SO
Q902 8-729-037-53 TRANSISTOR 2SB1462J-QR (K8).SO
Q903 8-729-037-52 TRANSISTOR 2SD2216J-QR (K8).SO
Q904 8-729-037-53 TRANSISTOR 2SB1462J-QR (K8).SO
< RESISTOR >
R803 1-218-990-11 SHORT 0
R805 1-218-990-11 SHORT 0
R808 1-218-969-11 RES-CHIP 22K 5% 1/16W
R809 1-218-966-11 RES-CHIP 12K 5% 1/16W
R810 1-218-990-11 SHORT 0
To Next Page
