6-9
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
PD-128 SL-56
R812 1-218-973-11 RES-CHIP 47K 5% 1/16W
R813 1-218-967-11 RES-CHIP 15K 5% 1/16W
R814 1-218-971-11 RES-CHIP 33K 5% 1/16W
R817 1-218-966-11 RES-CHIP 12K 5% 1/16W
R818 1-218-972-11 RES-CHIP 39K 5% 1/16W
R820 1-218-977-11 RES-CHIP 100K 5% 1/16W
R821 1-218-965-11 RES-CHIP 10K 5% 1/16W
R904 1-218-973-11 RES-CHIP 47K 5% 1/16W
R905 1-218-973-11 RES-CHIP 47K 5% 1/16W
R908 1-218-987-11 RES-CHIP 680K 5% 1/16W
R909 1-218-979-11 RES-CHIP 150K 5% 1/16W
(J, CND, UK, E, HK, AUS, CN, KR, JE)
R909 1-218-978-11 RES-CHIP 120K 5% 1/16W
(US, AEP)
R910 1-218-977-11 RES-CHIP 100K 5% 1/16W
R911 1-218-965-11 RES-CHIP 10K 5% 1/16W
R912 1-218-989-11 RES-CHIP 1M 5% 1/16W
R913 1-218-990-11 SHORT 0
R914 1-218-989-11 RES-CHIP 1M 5% 1/16W
R915 1-218-969-11 RES-CHIP 22K 5% 1/16W
R916 1-218-975-11 RES-CHIP 68K 5% 1/16W
R917 1-218-975-11 RES-CHIP 68K 5% 1/16W
R918 1-218-973-11 RES-CHIP 47K 5% 1/16W
R919 1-218-891-11 METAL CHIP 68K 0.5% 1/16W
R920 1-218-883-11 METAL CHIP 33K 0.5% 1/16W
R921 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R922 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R925 1-218-977-11 RES-CHIP 100K 5% 1/16W
R926 1-218-971-11 RES-CHIP 33K 5% 1/16W
R928 1-218-977-11 RES-CHIP 100K 5% 1/16W
R929 1-218-977-11 RES-CHIP 100K 5% 1/16W
R932 1-218-977-11 RES-CHIP 100K 5% 1/16W
R933 1-218-971-11 RES-CHIP 33K 5% 1/16W
R934 1-218-990-11 SHORT 0
R935 1-218-883-11 METAL CHIP 33K 0.5% 1/16W
R936 1-218-879-11 METAL CHIP 22K 0.5% 1/16W
R937 1-218-883-11 METAL CHIP 33K 0.5% 1/16W
R938 1-218-879-11 METAL CHIP 22K 0.5% 1/16W
R960 1-218-937-11 RES-CHIP 47 5% 1/16W
R961 1-218-937-11 RES-CHIP 47 5% 1/16W
R962 1-218-937-11 RES-CHIP 47 5% 1/16W
PPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
A-7074-364-A SL-56 BOARD, COMPLETE
**********************
(Ref.No.:2, 000 Series)
< BATTERY >
0 BT151 1-528-999-11 BATTERY, LITHIUM SECONDARY
< CAPACITOR >
C151 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C251 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C252 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C253 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C255 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C301 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN151 1-691-371-21 CONNECTOR, FFC/FPC 7P
CN251 1-779-332-11 CONNECTOR, FFC/FPC 16P
CN252 1-794-335-11 CONNECTOR (USB) (4P), SQUARE
CN301 1-766-339-21 CONNECTOR, FFC/FPC 9P
CN302 1-691-360-11 CONNECTOR, FFC/FPC (ZIF) 22P
< DIODE >
D151 8-719-073-01 DIODE MA111- (K8).S0
D152 8-719-045-87 DIODE MA4Z082WA- (TX).SO
D153 8-719-045-87 DIODE MA4Z082WA- (TX).SO
D154 8-719-045-87 DIODE MA4Z082WA- (TX).SO
D251 8-719-045-87 DIODE MA4Z082WA- (TX).SO
D253 8-719-045-87 DIODE MA4Z082WA- (TX).SO
D255 8-719-073-01 DIODE MA111- (K8).S0
D256 8-719-073-01 DIODE MA111- (K8).S0
D257 8-719-045-87 DIODE MA4Z082WA- (TX).SO
D259 8-719-045-87 DIODE MA4Z082WA- (TX).SO
D260 8-719-073-01 DIODE MA111- (K8).S0
D261 8-719-159-96 DIODE RD5.1UM-T1B
D262 8-719-159-96 DIODE RD5.1UM-T1B
D263 8-719-045-87 DIODE MA4Z082WA- (TX).SO
D264 8-719-045-87 DIODE MA4Z082WA- (TX).SO
D265 8-719-045-87 DIODE MA4Z082WA- (TX).SO
D266 8-719-045-87 DIODE MA4Z082WA- (TX).SO
D301 8-719-060-92 DIODE SML-311YTT86 (STROB)
D302 8-719-074-30 DIODE SML-310LTT86 (TARRY)
D303 8-719-063-83 DIODE SML-310MTT86 (AE LOCK)
< INDUCTOR >
FB251 1-500-284-21 INDUCTOR CHIP 0uH
FB252 1-500-284-21 INDUCTOR CHIP 0uH
FB253 1-500-284-21 INDUCTOR CHIP 0uH
FB254 1-500-284-21 INDUCTOR CHIP 0uH
FB255 1-500-284-21 INDUCTOR CHIP 0uH
FB301 1-414-228-11 INDUCTOR CHIP 0uH
< IC >
IC301 8-759-573-02 IC BU9735K-E2
< JACK >
J251 1-695-514-31 JACK (SMALL TYPE) 1P (A/V OUT)
J252 1-793-995-21 JACK, SUPER SMALL TYPE (EXT FLASH)
< LINE FILTER >
LF001 1-419-100-21 COIL, COMMON-MODE CHOKE
LF002 1-419-100-21 COIL, COMMON-MODE CHOKE
LF003 1-419-100-21 COIL, COMMON-MODE CHOKE
LF004 1-419-100-21 COIL, COMMON-MODE CHOKE
< RESISTOR >
R152 1-218-956-11 RES-CHIP 1.8K 5% 1/16W
R153 1-218-967-11 RES-CHIP 15K 5% 1/16W
R155 1-218-956-11 RES-CHIP 1.8K 5% 1/16W
R158 1-218-958-11 RES-CHIP 2.7K 5% 1/16W
R159 1-218-958-11 RES-CHIP 2.7K 5% 1/16W
R160 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
