6-10
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
SL-56
R161 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R162 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R163 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R164 1-218-971-11 RES-CHIP 33K 5% 1/16W
R251 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R252 1-218-953-11 RES-CHIP 1K 5% 1/16W
R253 1-218-977-11 RES-CHIP 100K 5% 1/16W
R256 1-218-989-11 RES-CHIP 1M 5% 1/16W
R262 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R263 1-218-985-11 RES-CHIP 470K 5% 1/16W
R264 1-218-990-11 SHORT 0
R301 1-218-949-11 RES-CHIP 470 5% 1/16W
R302 1-218-949-11 RES-CHIP 470 5% 1/16W
R303 1-218-945-11 RES-CHIP 220 5% 1/16W
R304 1-218-987-11 RES-CHIP 680K 5% 1/16W
R305 1-218-977-11 RES-CHIP 100K 5% 1/16W
R306 1-218-977-11 RES-CHIP 100K 5% 1/16W
< SWITCH >
S151 1-771-688-21 SWITCH, TACTILE (CONTROL BUTTON)
S152 1-771-138-61 SWITCH, KEY BOARD (PROGRAM AE)
S153 1-771-138-61 SWITCH, KEY BOARD (DISPLAY)
S154 1-771-138-61 SWITCH, KEY BOARD (FLASH)
S155 1-771-138-61 SWITCH, KEY BOARD
(VOLUME/PROGRAM AE +)
S156 1-771-138-61 SWITCH, KEY BOARD (FOCUS)
S157 1-771-138-61 SWITCH, KEY BOARD
(VOLUME/PROGRAM AE -)
S158 1-771-138-61 SWITCH, KEY BOARD (LCD BACK LIGHT)
PPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
MISCELLANEOUS
***************
9 1-418-985-11 SWITCH BLOCK, CONTROL (MODE SW)
0 61 1-476-005-11 FLASH UNIT
101 1-677-877-11 FP-024 FLEXIBLE BOARD
102 1-677-879-11 FP-028 FLEXIBLE BOARD
104 1-960-457-11 HARNESS (YP-052) (14P)
112 1-960-456-11 HARNESS (YP-051) (12P)
0 113 1-794-045-11 CONNECTOR, DC-IN
114 1-418-986-11 SWITCH BLOCK, CONTROL
(ZOOM/POWER SW)
115 1-677-878-11 FP-027 FLEXIBLE BOARD
116 1-677-881-11 FP-031 FLEXIBLE BOARD
118 1-677-880-11 FP-029 FLEXIBLE BOARD
0 129 1-418-879-11 TRANSFORMER UNIT, INVERTER
152 A-7031-106-A LENS ASSY (VCL-7003XA)
156 1-677-875-21 FP-021 FLEXIBLE BOARD
161 1-758-437-11 FILTER BLOCK, OPTICAL
BT901 1-694-654-11 TERMINAL BOARD, BATTERY
IC401 A-7031-084-A CCD BLOCK ASSY (CCD IMAGER)
SP901 1-505-862-31 SPEAKER (2.0 cm)
LCD901 1-803-857-21 INDICATOR MODULE LIQUID CRYSTAL
LCD902 1-803-975-21 DISPLAY PANEL, LIQUID CRYSTAL
0ND901 1-517-878-31 TUBE, FLUORESCENT, COLD CATHODE
MIC901 1-542-428-11 MICROPHONE UNIT
PPPPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
ACCESSORIES & PACKING MATERIALS
********************************
0 1-475-599-11 ADAPTOR, AC (EXCEPT KR)
0 1-475-599-71 ADAPTOR, AC (KR)
0 1-569-007-11 ADAPTOR, CONVERSION 2P (JE)
0 1-569-008-21 ADAPTOR, CONVERSION 2P (E)
0 1-696-819-11 CORD, POWER (AUS)
0 1-769-608-11 CORD, POWER (AEP, E)
0 1-776-985-11 CORD, POWER (KR)
0 1-782-476-11 CORD, POWER (CN)
0 1-783-374-11 CORD, POWER (UK, HK)
1-783-738-31 CORD, CONNECTION
(A/V connecting cable 1.5m)
0 1-790-073-11 CORD, POWER 2P (J, JE)
0 1-790-107-22 CORD, POWER (US, CND)
1-791-785-11 CORD, CONNECTION (USB CABLE) (J)
1-792-623-11 CABLE, USB (EXCEPT J)
3-060-522-01 MANUAL, INSTRUCTION (JAPANESE) (J)
3-060-522-11 MANUAL, INSTRUCTION (ENGLISH)
(US, CND, AEP, UK, E, HK, AUS, CN, JE)
3-060-522-21 MANUAL, INSTRUCTION
(FRENCH, GERMAN) (CND, AEP, JE)
3-060-522-31 MANUAL, INSTRUCTION
(SPANISH, PORTUGUESE) (AEP, E, JE)
3-060-522-41 MANUAL, INSTRUCTION (ITALIAN, DUTCH)
(AEP)
3-060-522-51 MANUAL, INSTRUCTION (CHINESE)
(E, HK, CN, JE)
3-060-522-61 MANUAL, INSTRUCTION
(RUSSIAN, SWEDISH) (AEP, JE)
3-060-522-71 MANUAL, INSTRUCTION (ARABIC) (E)
3-060-522-81 MANUAL, INSTRUCTION (KOREAN) (KR, JE)
3-060-716-01 SOFT (2000), BUNDLE
3-061-217-01 STRING, CAP
3-866-482-01 MANUAL, INSTRUCTION (for SAFETY)
(JAPANESE) (J)
3-987-015-01 BELT (S), SHOULDER
X-3950-542-2 CAP ASSY, LENS
(Note) Be sure to read “Precautions for Replcement of
CCD Imager” on page 4-8 when changing
the CCD imager
To Next Page
