Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-AZ33D
106
R841 1-216-864-11 SHORT CHIP 0
R842 1-216-833-11 METAL CHIP 10K 5% 1/10W
R850 1-216-845-11 METAL CHIP 100K 5% 1/10W
R851 1-216-845-11 METAL CHIP 100K 5% 1/10W
R852 1-216-845-11 METAL CHIP 100K 5% 1/10W
R855 1-216-845-11 METAL CHIP 100K 5% 1/10W
R856 1-216-845-11 METAL CHIP 100K 5% 1/10W
R857 1-216-845-11 METAL CHIP 100K 5% 1/10W
R858 1-216-841-11 METAL CHIP 47K 5% 1/10W
R859 1-216-841-11 METAL CHIP 47K 5% 1/10W
R880 1-216-837-11 METAL CHIP 22K 5% 1/10W
R881 1-216-837-11 METAL CHIP 22K 5% 1/10W
R882 1-216-837-11 METAL CHIP 22K 5% 1/10W
R883 1-216-837-11 METAL CHIP 22K 5% 1/10W
R884 1-216-837-11 METAL CHIP 22K 5% 1/10W
R885 1-216-839-11 METAL CHIP 33K 5% 1/10W
R886 1-216-864-11 SHORT CHIP 0
R887 1-216-837-11 METAL CHIP 22K 5% 1/10W
R888 1-216-837-11 METAL CHIP 22K 5% 1/10W
R889 1-216-837-11 METAL CHIP 22K 5% 1/10W
R890 1-216-837-11 METAL CHIP 22K 5% 1/10W
R891 1-216-839-11 METAL CHIP 33K 5% 1/10W
R892 1-216-864-11 SHORT CHIP 0
R893 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R894 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R895 1-216-837-11 METAL CHIP 22K 5% 1/10W
< VIBRATOR >
X800 1-814-046-11 VIBRATOR, CRYSTAL (49MHz)
************************************************************
SPEAKER BOARD
**************
< CAPACITOR >
C521 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C522 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C531 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C532 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CN501 1-564-241-11 PIN, CONNECTOR (3.96mm PITCH) 4P
< EARTH TERMINAL >
ET501 1-537-738-21 TERMINAL, GROUND
< TERMINAL >
TB501 1-821-164-11 TERMINAL BOARD (SPEAKER) 2P (SPEAKER)
************************************************************
A-1252-800-A TOUCH SENSOR BOARD, COMPLETE
******************************
< CAPACITOR >
C002 1-126-603-11 ELECT CHIP 4.7uF 20% 35V
C006 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C007 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C008 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C009 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C010 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C011 1-126-603-11 ELECT CHIP 4.7uF 20% 35V
< CONNECTOR >
CN004 1-784-365-51 CONNECTOR, FFC/FPC 5P
CN005 1-784-370-51 CONNECTOR, FFC/FPC 11P
< LED >
D001 6-501-216-01 LED CL-271HR-C-TS
(TOUCH SENSOR BACK LIGHT)
D002 6-501-216-01 LED CL-271HR-C-TS
(TOUCH SENSOR BACK LIGHT)
D003 6-501-216-01 LED CL-271HR-C-TS
(TOUCH SENSOR BACK LIGHT)
D004 6-501-216-01 LED CL-271HR-C-TS
(TOUCH SENSOR BACK LIGHT)
D006 6-501-216-01 LED CL-271HR-C-TS
(TOUCH SENSOR BACK LIGHT)
D007 6-501-216-01 LED CL-271HR-C-TS
(TOUCH SENSOR BACK LIGHT)
D009 6-501-216-01 LED CL-271HR-C-TS
(TOUCH SENSOR BACK LIGHT)
D010 6-501-216-01 LED CL-271HR-C-TS
(TOUCH SENSOR BACK LIGHT)
D011 6-501-216-01 LED CL-271HR-C-TS
(TOUCH SENSOR BACK LIGHT)
D012 6-501-216-01 LED CL-271HR-C-TS
(TOUCH SENSOR BACK LIGHT)
< IC >
IC003 6-705-337-01 IC TK11150CSCL-G
IC004 6-711-521-01 IC CP6683AMT
< TRANSISTOR >
Q001 6-550-260-01 TRANSISTOR RT1N237M-TP-1
Q002 6-550-260-01 TRANSISTOR RT1N237M-TP-1
< RESISTOR >
R001 1-216-817-11 METAL CHIP 470 5% 1/10W
R002 1-216-817-11 METAL CHIP 470 5% 1/10W
R003 1-216-817-11 METAL CHIP 470 5% 1/10W
R004 1-216-817-11 METAL CHIP 470 5% 1/10W
R005 1-216-817-11 METAL CHIP 470 5% 1/10W
R006 1-216-817-11 METAL CHIP 470 5% 1/10W
R007 1-216-817-11 METAL CHIP 470 5% 1/10W
R008 1-216-817-11 METAL CHIP 470 5% 1/10W
R009 1-216-817-11 METAL CHIP 470 5% 1/10W
R010 1-216-817-11 METAL CHIP 470 5% 1/10W
R011 1-216-817-11 METAL CHIP 470 5% 1/10W
R012 1-216-817-11 METAL CHIP 470 5% 1/10W
R013 1-216-817-11 METAL CHIP 470 5% 1/10W
R014 1-216-817-11 METAL CHIP 470 5% 1/10W
R015 1-216-817-11 METAL CHIP 470 5% 1/10W
R016 1-216-809-11 METAL CHIP 100 5% 1/10W
R017 1-216-809-11 METAL CHIP 100 5% 1/10W
R018 1-216-809-11 METAL CHIP 100 5% 1/10W
R019 1-216-809-11 METAL CHIP 100 5% 1/10W
R020 1-216-809-11 METAL CHIP 100 5% 1/10W
R021 1-216-809-11 METAL CHIP 100 5% 1/10W
R022 1-216-809-11 METAL CHIP 100 5% 1/10W
R023 1-216-809-11 METAL CHIP 100 5% 1/10W
R024 1-216-809-11 METAL CHIP 100 5% 1/10W
R025 1-216-809-11 METAL CHIP 100 5% 1/10W
S-MASTER SPEAKER TOUCH SENSOR
To Next Page
