Sony HCD-AZ33D - Page 107

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-AZ33D
107107
R030 1-216-817-11 METAL CHIP 470 5% 1/10W
R031 1-216-817-11 METAL CHIP 470 5% 1/10W
R032 1-216-817-11 METAL CHIP 470 5% 1/10W
R033 1-216-817-11 METAL CHIP 470 5% 1/10W
R034 1-216-817-11 METAL CHIP 470 5% 1/10W
R037 1-216-817-11 METAL CHIP 470 5% 1/10W
R038 1-216-817-11 METAL CHIP 470 5% 1/10W
R039 1-216-817-11 METAL CHIP 470 5% 1/10W
R040 1-216-817-11 METAL CHIP 470 5% 1/10W
R041 1-216-817-11 METAL CHIP 470 5% 1/10W
R042 1-216-833-11 METAL CHIP 10K 5% 1/10W
R044 1-216-833-11 METAL CHIP 10K 5% 1/10W
R047 1-216-864-11 SHORT CHIP 0
R048 1-216-864-11 SHORT CHIP 0
R049 1-216-864-11 SHORT CHIP 0
************************************************************
USB CONNECTOR BOARD
*********************
< CAPACITOR >
C001 1-126-176-11 ELECT 220uF 20% 10V
C002 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C003 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN001 1-794-548-21 CONNECTOR, USB (A) (USB)
CN002 1-784-766-11 CONNECTOR, FFC 5P
CN003 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
< DIODE >
D001 8-719-978-33 DIODE DTZ-TT11-6.8B
D002 8-719-978-33 DIODE DTZ-TT11-6.8B
< EARTH TERMINAL >
ET101 1-537-738-21 TERMINAL, GROUND
************************************************************
VIDEO BOARD
************
< CAPACITOR >
C1201 1-126-960-11 ELECT 1uF 20% 50V
C1202 1-126-960-11 ELECT 1uF 20% 50V
C1203 1-126-960-11 ELECT 1uF 20% 50V
C1204 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1205 1-126-965-91 ELECT 22uF 20% 50V
C1206 1-126-960-11 ELECT 1uF 20% 50V
C1207 1-126-960-11 ELECT 1uF 20% 50V
C1208 1-126-960-11 ELECT 1uF 20% 50V
C1209 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1210 1-104-658-91 ELECT 100uF 20% 10V
C1211 1-126-916-11 ELECT 1000uF 20% 6.3V
C1212 1-126-916-11 ELECT 1000uF 20% 6.3V
C1213 1-126-916-11 ELECT 1000uF 20% 6.3V
C1214 1-126-916-11 ELECT 1000uF 20% 6.3V
C1215 1-126-916-11 ELECT 1000uF 20% 6.3V
C1216 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1217 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1218 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1219 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1221 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1223 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1224 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C1227 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN1201 1-793-565-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN1203 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
< EARTH TERMINAL >
EP1201 1-537-738-21 TERMINAL, GROUND
EP1202 1-537-738-21 TERMINAL, GROUND
< JUMPER RESISTOR >
FB1201 1-216-864-11 SHORT CHIP 0
FB1202 1-216-864-11 SHORT CHIP 0
FB1203 1-216-864-11 SHORT CHIP 0
FB1204 1-216-864-11 SHORT CHIP 0
FB1205 1-216-864-11 SHORT CHIP 0
FB1206 1-216-864-11 SHORT CHIP 0
FB1210 1-216-864-11 SHORT CHIP 0
< IC >
IC1201 6-710-470-01 IC MM1758AFBE
< JACK >
J1201 1-537-943-11 TERMINAL, S (S VIDEO OUT)
J1202 1-785-867-11 JACK, PIN 1P (VIDEO OUT)
J1203 1-793-445-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
< JUMPER RESISTOR >
JR1201 1-216-295-91 SHORT CHIP 0
JR1202 1-216-296-11 SHORT CHIP 0
JR1220 1-216-864-11 SHORT CHIP 0
JR1225 1-216-864-11 SHORT CHIP 0
< COIL >
L1201 1-412-058-11 INDUCTOR 10uH
< RESISTOR >
R1202 1-216-809-11 METAL CHIP 100 5% 1/10W
R1203 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1204 1-218-285-11 METAL CHIP 75 5% 1/10W
R1205 1-218-285-11 METAL CHIP 75 5% 1/10W
R1206 1-218-285-11 METAL CHIP 75 5% 1/10W
R1207 1-218-285-11 METAL CHIP 75 5% 1/10W
R1208 1-218-285-11 METAL CHIP 75 5% 1/10W
R1209 1-216-809-11 METAL CHIP 100 5% 1/10W
R1210 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1211 1-218-285-11 METAL CHIP 75 5% 1/10W
************************************************************
TOUCH SENSOR USB CONNECTOR VIDEO
