HCD-AZ33D
73
Pin No. Pin Name I/O Description
56 to 64
HA2 to HA8, HA18,
HA19
O Address signal output to the fl ash ROM
65 DVDD3 - Power supply terminal (+3.3V)
66 XWR O Write enable signal output to the fl ash ROM
67 to 75 HA16 to HA9, HA20 O Address signal output to the fl ash ROM
76 XROMCS O Chip select signal output to the fl ash ROM
77 HA1 O Address signal output to the fl ash ROM
78 XRD O Read enable signal output to the fl ash ROM
79, 80 HD0, HD1 I/O Two-way data bus with the fl ash ROM
81 DVSS - Ground terminal
82 to 86 HD2 to HD6 I/O Two-way data bus with the fl ash ROM
87 HA21 O Address signal output to the fl ash ROM
88 ALE O Address latch enable signal output terminal Not used
89 HD7 I/O Data/address signal input/output terminal with the fl ash ROM
90 DVSS - Ground terminal
91, 92 HA17, HA0 O Address signal output to the fl ash ROM
93 DVDD18 - Power supply terminal (+1.8V)
94 UWR O Write enable signal output terminal Not used
95 URD O Data read enable signal output terminal Not used
96 DVDD3 - Power supply terminal (+3.3V)
97 IFSDO O Serial data output to the system controller
98 IFCK O Serial data transfer clock signaloutput to the system controller
99 XIFCS I Chip select signal input from the system controller
100 IFSDI I Serial data input from the system controller
101 SCL O Serial data transfer clock signal output to the EEPROM and D/A converter
102 SDA I/O Two-way data bus with the EEPROM and D/A converter
103 HDMI_SCL O Serial data transfer clock signal output terminal for HDMI section Not used
104 HDMI_SDA I/O Two-way data bus terminal for HDMI section Not used
105 RXD I Receive data input terminal for UART communication when data writing to fl ash memory
106 TXD O Transmit data output terminal for UART communication when data writing to fl ash memory
107 ICE I ICE mode enable signal input terminal Not used
108 XSYSRST I Reset signal input from the system controller "L": reset
109 IR I IR control signal input terminal Not used
110 XTXINT O Interrupt request signal output terminal Not used
111 DQM0 O Data mask signal output to the SD-RAM
112 IFBSY I Busy signal input from the system controller
113 to 117 RD7 to RD3 I/O Two-way data bus with the SD-RAM
118 DVDD3 - Power supply terminal (+3.3V)
119 to 129
RD2 to RD0, RD15 to
RD8
I/O Two-way data bus with the SD-RAM
130 LIMITSW I Limit detection switch input terminal
131 DVDD3 - Power supply terminal (+3.3V)
132 DQM1 O Data mask signal output to the SD-RAM
133 RWE O Write enable signal output to the SD-RAM
134 CAS O Column address strobe signal output to the SD-RAM
135 RAS O Row address strobe signal output to the SD-RAM
136 RCS O Chip select signal output to the SD-RAM
137, 138 BA0, BA1 O Bank address signal output to the SD-RAM
139 to 141 RA10, RA0, RA1 O Address signal output to the SD-RAM
142 DVDD18 - Power supply terminal (+1.8V)
143, 144 RA2, RA3 O Address signal output to the SD-RAM
145 DVDD3 - Power supply terminal (+3.3V)
146 DRCLK O Serial data transfer clock signal output to the SD-RAM
147 CKE O Clock enable signal output to the SD-RAM
148 DVSS - Ground terminal
149 to 155 RA11, RA9 to RA4 O Address signal output to the SD-RAM
