Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-AZ33D
94
R1553 1-216-864-11 SHORT CHIP 0
R1556 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1557 1-216-809-11 METAL CHIP 100 5% 1/10W
R1559 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1561 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1563 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1564 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R2501 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R2502 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3501 1-216-864-11 SHORT CHIP 0
R3502 1-216-809-11 METAL CHIP 100 5% 1/10W
R3503 1-216-809-11 METAL CHIP 100 5% 1/10W
R3610 1-216-864-11 SHORT CHIP 0
R3651 1-216-864-11 SHORT CHIP 0
R3652 1-216-805-11 METAL CHIP 47 5% 1/10W
R3653 1-216-864-11 SHORT CHIP 0
R3711 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3712 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3713 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3714 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3715 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3716 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3717 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3718 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3719 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3721 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3722 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3723 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3724 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3725 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3726 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3727 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3728 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3729 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3771 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3772 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3773 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3774 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3775 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3776 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3777 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3778 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3779 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3781 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3782 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R3783 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3784 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3785 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3786 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3787 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3788 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3789 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3801 1-216-864-11 SHORT CHIP 0
R3802 1-216-864-11 SHORT CHIP 0
R3803 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3804 1-216-836-11 METAL CHIP 18K 5% 1/10W
R3805 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4701 1-216-864-11 SHORT CHIP 0
R4702 1-216-864-11 SHORT CHIP 0
R4703 1-216-864-11 SHORT CHIP 0
R4704 1-216-864-11 SHORT CHIP 0
R4705 1-216-864-11 SHORT CHIP 0
R4706 1-216-864-11 SHORT CHIP 0
R5002 1-216-864-11 SHORT CHIP 0
R5016 1-216-864-11 SHORT CHIP 0 (EXCEPT PH, SP, TH)
R5017 1-216-864-11 SHORT CHIP 0 (PH, SP, TH)
< COMPOSITION CIRCUIT BLOCK >
RB103 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB104 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB105 1-234-371-21 RES, NETWORK 47 (1005X4)
RB106 1-234-371-21 RES, NETWORK 47 (1005X4)
RB108 1-234-370-21 RES, NETWORK 22 (1005X4)
RB110 1-234-370-21 RES, NETWORK 22 (1005X4)
RB111 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB112 1-234-370-21 RES, NETWORK 22 (1005X4)
RB113 1-234-370-21 RES, NETWORK 22 (1005X4)
RB114 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB115 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
< VIBRATOR >
X101 1-813-539-11 QUARTZ CRYSTAL UNIT (27MHz)
************************************************************
A-1244-280-A DMPORT BOARD, COMPLETE
************************
< CAPACITOR >
C210 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C211 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C229 1-126-193-11 ELECT CHIP 1uF 20% 50V
C230 1-126-193-11 ELECT CHIP 1uF 20% 50V
C231 1-126-193-11 ELECT CHIP 1uF 20% 50V
C232 1-126-193-11 ELECT CHIP 1uF 20% 50V
C237 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C238 1-126-395-11 ELECT CHIP 22uF 20% 16V
C239 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C240 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C241 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN201 1-784-861-51 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
CN203 1-770-469-41 PIN, CONNECTOR (PC BOARD) 2P
CN204 1-817-615-21 CONNECTOR BOARD TO BOARD 18P
< IC >
IC202 8-759-100-96 IC uPC4558G2
< COIL >
L200 1-469-555-21 INDUCTOR 10uH
< RESISTOR >
R203 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R204 1-216-864-11 SHORT CHIP 0
R205 1-216-809-11 METAL CHIP 100 5% 1/10W
R206 1-216-864-11 SHORT CHIP 0
R207 1-216-864-11 SHORT CHIP 0
R208 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R209 1-216-845-11 METAL CHIP 100K 5% 1/10W
DMB17 DMPORT
