Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-AZ33D
9595
R214 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R215 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R224 1-216-809-11 METAL CHIP 100 5% 1/10W
R227 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R228 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R229 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R230 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R231 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R232 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R239 1-216-864-11 SHORT CHIP 0
R241 1-216-296-11 SHORT CHIP 0
************************************************************
EJECT BOARD
************
< CONNECTOR >
CN101 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
< RESISTOR >
R101 1-216-837-11 METAL CHIP 22K 5% 1/10W
< SWITCH >
S101 1-762-875-21 SWITCH, KEYBOARD (Z)
************************************************************
A-1249-497-A FL BOARD, COMPLETE
*******************
< CAPACITOR >
C201 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C202 1-126-965-91 ELECT 22uF 20% 50V
C203 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C204 1-126-967-11 ELECT 47uF 20% 50V
C205 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C206 1-162-922-11 CERAMIC CHIP 39PF 5% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-127-804-91 CERAMIC CHIP 100PF 1% 50V
C210 1-127-804-91 CERAMIC CHIP 100PF 1% 50V
C211 1-127-804-91 CERAMIC CHIP 100PF 1% 50V
C212 1-127-804-91 CERAMIC CHIP 100PF 1% 50V
C229 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C230 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN209 1-564-723-11 PIN, CONNECTOR (SMALL TYPE) 7P
CN211 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
CN212 1-784-739-11 CONNECTOR, FFC 17P
< DIODE >
D201 8-719-083-58 DIODE UDZSNPTE-173.9B
D202 8-719-404-50 DIODE MA111-TX
D203 8-719-404-50 DIODE MA111-TX
D204 8-719-404-50 DIODE MA111-TX
D205 8-719-404-50 DIODE MA111-TX
< FLUORESCENT INDICATOR TUBE >
FL201 1-519-941-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC201 6-705-899-01 IC ML9208-03MBZ03B
< JUMPER RESISTOR >
JR216 1-216-295-91 SHORT
CHIP 0
JR217 1-216-864-11 SHORT CHIP 0
JR218 1-216-864-11 SHORT CHIP 0
JR219 1-216-864-11 SHORT CHIP 0
< COIL >
L201 1-410-671-31 INDUCTOR 47uH
< TRANSISTOR >
Q201 6-550-065-01 TRANSISTOR CPH5504-TL-E
Q202 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q203 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R201 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R202 1-216-833-11 METAL CHIP 10K 5% 1/10W
R203 1-216-809-11 METAL CHIP 100 5% 1/10W
R204 1-216-809-11 METAL CHIP 100 5% 1/10W
R205 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R206 1-216-821-11 METAL CHIP 1K 5% 1/10W
R207 1-216-821-11 METAL CHIP 1K 5% 1/10W
R208 1-216-821-11 METAL CHIP 1K 5% 1/10W
R209 1-216-821-11 METAL CHIP 1K 5% 1/10W
R210 1-216-837-11 METAL CHIP 22K 5% 1/10W
R211 1-216-837-11 METAL CHIP 22K 5% 1/10W
R212 1-216-833-11 METAL CHIP 10K 5% 1/10W
R213 1-216-833-11 METAL CHIP 10K 5% 1/10W
R214 1-216-864-11 SHORT CHIP 0
< TRANSFORMER >
T201 1-443-576-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
A-1249-506-A HP MIC BOARD, COMPLETE
**********************
< CAPACITOR >
C1060 1-124-257-00 ELECT 2.2uF 20% 50V
C1061 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1062 1-124-257-00 ELECT 2.2uF 20% 50V
C1063 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1064 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1065 1-124-465-00 ELECT 0.47uF 20% 50V
C1066 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1067 1-164-816-11 CERAMIC CHIP 220PF 2% 50V
C1068 1-124-257-00 ELECT 2.2uF 20% 50V
C1069 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1070 1-164-816-11 CERAMIC CHIP 220PF 2% 50V
C1071 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1072 1-124-247-91 ELECT 10uF 20% 35V
C1074 1-126-176-11 ELECT 220uF 20% 10V
C1078 1-124-257-00 ELECT 2.2uF 20% 50V
C1095 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1098 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1115 1-136-177-00 FILM 1uF 5% 50V
C1117 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
FLDMPORT EJECT HP MIC
