14
HCD-FL7D
3-6. FRONT PANEL ASSY
3-7. GC BOARD
two claws
qg
Rifting up the CD mechanism block
section, and release two claws.
7
connector
(CN1)
8
connector
(CN808)
9
connector
(CN318)
1
wire (flat type) (15 core)
(CN206)
5
wire (flat type)
(17 core) (CN109)
2
connector
(CN201)
3
connector
(CN203)
4
connector
(CN207)
6
connector
(CN2)
qf
two screws
(BVTP3
×
8)
0
screw
(BVTP3
×
8)
qs
screw
(BVTP3
×
8)
qa
harness
qd
harness
qh
front panel assy
Saudi Arabia,
Korean, Mexican,
Singapore
4
three screws
(BVTP3
×
8)
2
wire (flat type) (19 core)
(CN202)
1
wire (flat type) (17 core)
(CN204)
3
connector
(CN713)
5
GC board
