Sony HCD-FL7D - PRINTED WIRING BOARD - MC Board -

HCD-FL7D
6666
MC BOARD
IC101
1
30
31
50
51
80
81
100
IC201
K
SP RELAY
BOARD
CN806
L
SP RELAY
BOARD
CN805
13
E
(CHASSIS)
EE
M
DSP BOARD
CN601
N
DSP BOARD
CN602
∗ TUNER PACK
AM
AM
75Ω
ANTENNA
∗ SUPPLIED WITH
THE ASSEMBLED BLOCK
B
MB BOARD
CN907
(CHASSIS)
E
E
E
E
E
EE
1
3
Q
GC BOARD
CN202
O
SUB TRANS
BOARD
CN903
P
SUB TRANS
BOARD
CN903
(EA, MX, SP, KR)
I
SW BOARD
CN1001
1-685-087-
11
(11)
A
B
C
D
E
F
1 2 3 4 5 6 7 8 9
(US, CND, AEP, UK)
11
(21)
EXCEPT
AEP, UK
(AEP, UK)
NC
NC
EXCEPT
AEP, UK
(AEP, UK)
(AEP, UK)
(AEP, UK)
(AEP, UK)
11
(EXCEPT AEP, UK)
EXCEPT
AEP, UK
IC202
JR102
JR101
8-28. PRINTED WIRING BOARD – MC Board – • See page 45 for Circuit Boards Location.
D101 E-4
D102 E-5
D103 E-5
D104 E-6
D105 E-4
D106 B-2
D202 E-3
D203 F-3
D204 F-3
D205 F-2
D206 F-9
D207 F-8
D208 F-8
D211 F-8
D212 F-8
IC101 D-5
IC201 E-3
IC202 F-8
Q202 D-3
Q203 E-3
Q251 D-8
Q252 D-8
Q253 E-8
Q254 E-8
Q255 E-8
Q256 E-7
Q257 E-7
• Semiconductor
Location
Ref. No. Location
(Page 78)
(Page 78)
(Page 69) (Page 69)
(Page 48)
(Page 90)
(Page 91)
(Page 82)
(Page 62)
