HCD-FL7D
3-10. SW BOARD, HEAD (A) BOARD, HEAD (B) BOARD
3-11. DVD MECHANISM BLOCK
6
screw (PTT 2
×
4)
4
screw (PTT 2
×
4)
3
SW board
2
five claws
5
head (A) board
7
head (B) board
1
Remove the four solders.
8
two connectors
(CN805, 806)
9
claw
6
two connectors
(CN702, 703)
0
two claws
SP-relay
board
MC board
qa
DVD mechanism block
3
connector
(CN905)
4
connector
(CN903)
1
wire (flat type)
(11 core: EXCEPT AEP, UK)/
wire (flat type)
(15 core: AEP, UK)
(CN105)
2
wire (flat type)
(17 core) (CN204)
5
connector
(CN807)
7
six screws
