Sony HCD-FL7D - SP RELAY Board

22
HCD-FL7D
2 screw (BVTP3 × 8)
1 two screws
(BVTP3 × 8)
4 two connectors
(CN803, 804)
6 connector
(CN801)
7 SP relay board
5 two claws
front rear AMP board
center SW AMP board
3 chassis
3-22. SP RELAY BOARD
