HCD-FL7D
3-20. BACK COVER SECTION
3-21. TRANS BOARD
5 TRANS board
4 four screws
3 connector (CN915)
1 connector (CN914)
2 connector (CN916)
4 two screws
(BVTP3 × 8)
1 connector
(CN902)
2 connector
(CN809)
6 back cover section
5 screw (BVTP3 × 8
)
3 connector
(CN901)
