139
HCD-FL7D
SECTION 10
ELECTRICAL PARTS LIST
BLUE LED
CD DOOR CD DOOR SW1
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
1-684-201-11 BLUE LED BOARD
***************
< CAPACITOR >
C316 1-164-357-11 CERAMIC CHIP 0.001uF 5% 50V
< LED >
D308 6-500-329-01 LED SELU5E23C-PTP15
(MULTI CHANNEL DECODING)
< RESISTOR >
R381 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R382 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R383 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R384 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R385 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R386 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R387 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R388 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
**************************************************************
1-684-203-11 CD DOOR BOARD
**************
< CAPACITOR >
C341 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C342 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C343 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN317 1-565-856-11 SOCKET, CONNECTOR 8P
< LED >
D341 8-719-071-41 LED SELS5923C-TP15 (DISC 1 INDICATOR)
D342 8-719-071-41 LED SELS5923C-TP15 (DISC 2 INDICATOR)
D343 8-719-071-41 LED SELS5923C-TP15 (DISC 3 INDICATOR)
D344 8-719-071-41 LED SELS5923C-TP15 (DISC 4 INDICATOR)
D345 8-719-071-41 LED SELS5923C-TP15 (DISC 5 INDICATOR)
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
< SHORT >
JR341 1-216-864-11 SHORT CHIP 0
JR342 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R333 1-216-864-11 SHORT CHIP 0
R334 1-216-864-11 SHORT CHIP 0
R335 1-216-864-11 SHORT CHIP 0
R336 1-216-864-11 SHORT CHIP 0
R337 1-216-864-11 SHORT CHIP 0
R341 1-216-797-11 RES-CHIP 10 5% 1/10W
R342 1-216-809-11 RES-CHIP 100 5% 1/10W
R343 1-216-809-11 RES-CHIP 100 5% 1/10W
R344 1-216-809-11 RES-CHIP 100 5% 1/10W
R345 1-216-809-11 RES-CHIP 100 5% 1/10W
R346 1-216-809-11 RES-CHIP 100 5% 1/10W
< SWITCH >
S341 1-477-173-11 ENCODER, ROTARY (VOLUME)
**************************************************************
1-684-204-11 CD DOOR SW1 BOARD
*******************
< SWITCH >
S331 1-571-300-21 SWITCH, LEVER SLIDE
(CD DOOR OPEN/CLOSE DETECT)
**************************************************************
1-684-205-11 CD DOOR SW2 BOARD
*******************
< SWITCH >
S332 1-771-821-11 SWITCH, PUSH (1 KEY)
(CD DOOR LOCK DETECT)
**************************************************************
•Abbreviation
CND : Canadian model
EA : Saudi Arabia model
KR : Korean model
MX : Mexican model
SP : Singapore model
CD DOOR SW2
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
