Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
140
HCD-FL7D
CD MOTOR CENTER SW AMP
1-684-202-11 CD MOTOR BOARD
****************
< CAPACITOR >
C303 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C304 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C305 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN309 1-569-909-11 SOCKET, CONNECTOR 15P
CN312 1-565-856-11 SOCKET, CONNECTOR 8P
CN313 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
CN314 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< DIODE >
D305 8-719-976-99 DIODE UDZ-TE-17-5.1B
< IC >
IC302 8-759-598-69 IC BA6956AN
< RESISTOR >
R315 1-216-805-11 RES-CHIP 47 5% 1/10W
R316 1-216-817-11 RES-CHIP 470 5% 1/10W
**************************************************************
A-4676-816-A CENTER SW AMP BOARD, COMPLETE
(US, CND)
A-4676-827-A CENTER SW AMP BOARD, COMPLETE
(EA, SP)
A-4676-838-A CENTER SW AMP BOARD, COMPLETE
(AEP, UK)
A-4730-196-A CENTER SW AMP BOARD, COMPLETE (MX)
A-4730-940-A CENTER SW AMP BOARD, COMPLETE (KR)
*********************
< CAPACITOR >
C501 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT US, CND)
C501 1-128-582-11 ELECT 10uF 20% 100V
(US, CND)
C502 1-162-290-31 CERAMIC 470PF 10% 50V
C503 1-162-282-31 CERAMIC 100PF 10% 50V
C504 1-126-965-11 ELECT 22uF 20% 50V
(EXCEPT US, CND)
C504 1-128-560-11 ELECT 22uF 20% 100V
(US, CND)
C505 1-136-165-00 FILM 0.1uF 5% 50V
C506 1-136-165-00 FILM 0.1uF 5% 50V
C507 1-128-560-11 ELECT 22uF 20% 100V
C508 1-128-560-11 ELECT 22uF 20% 100V
C519 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP, UK, KR)
C520 1-162-294-31 CERAMIC 0.001uF 10% 50V
C521 1-128-562-11 ELECT 47uF 20% 100V
C551 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT US, CND)
C551 1-128-582-11 ELECT 10uF 20% 100V
(US, CND)
C552 1-162-290-31 CERAMIC 470PF 10% 50V
C553 1-162-282-31 CERAMIC 100PF 10% 50V
C554 1-104-665-11 ELECT 100uF 20% 10V
(EXCEPT US, CND)
C554 1-126-968-11 ELECT 100uF 20% 50V
(US, CND)
C555 1-136-165-00 FILM 0.1uF 5% 50V
C556 1-136-165-00 FILM 0.1uF 5% 50V
C591 1-130-777-00 MYLAR 0.1uF 5% 100V
C592 1-130-777-00 MYLAR 0.1uF 5% 100V
C593 1-135-632-51 ELECT 2200uF 20% 63V
(EXCEPT MX)
C593 1-137-840-11 ELECT 2200uF 20% 63V
(MX)
C594 1-135-632-51 ELECT 2200uF 20% 63V
(EXCEPT MX)
C594 1-137-840-11 ELECT 2200uF 20% 63V
(MX)
C595 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, UK, KR)
C921 1-130-483-00 MYLAR 0.01uF 5% 50V
C922 1-130-483-00 MYLAR 0.01uF 5% 50V
C923 1-126-955-11 ELECT 4700uF 20% 35V
C925 1-126-964-11 ELECT 10uF 20% 50V
C926 1-126-767-11 ELECT 1000uF 20% 16V
C927 1-126-964-11 ELECT 10uF 20% 50V
C928 1-126-926-11 ELECT 1000uF 20% 10V
< CONNECTOR >
CN502 1-573-826-11 CONNECTOR, BOARD TO BOARD 12P
CN503 1-573-827-11 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D501 8-719-911-19 DIODE 1SS133T-72
D502 8-719-911-19 DIODE 1SS133T-72
D551 8-719-911-19 DIODE 1SS133T-72
D552 8-719-911-19 DIODE 1SS133T-72
D591 6-500-249-01 DIODE D15XB20 (EA, MX, SP, KR)
D591 6-500-250-01 DIODE D15XB20-4001 (US, CND, AEP, UK)
D921 8-719-028-23 DIODE D3SBA20-4101
< GROUND TERMINAL >
EP501 1-537-738-21 TERMINAL, GROUND (AEP, UK, KR)
EP502 1-537-738-21 TERMINAL, GROUND (AEP, UK, KR)
< IC >
IC501 8-749-016-96 IC STK402-120S (US, CND, AEP, UK)
IC501 8-749-017-16 IC STK442-130 (EA, MX, SP, KR)
IC921 8-759-518-68 IC PQ12RF21
IC922 8-759-701-59 IC TA7809S
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q521 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q522 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q551 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q922 8-729-116-02 TRANSISTOR BA1A4M-TP
Q923 8-729-116-02 TRANSISTOR BA1A4M-TP
