Sony HCD-FL7D - MB Board (Component Side)

HCD-FL7D
1212
R284
C928
R570
R571
R771
R773
FB901
(COMPONENT SIDE)
MB BOARD
IC401
IC801
IC401
IC906
IC902
IC904
IC901
IC215
IC206
105156
157
208
104
53
1
IC509
120
6041
21
40
80
61
IC701
MC BOARD
CN112
B
SS
71
SP RELAY
BOARD
NO816
C
DSP BOARD
CN603
D
28
19
VIDEO
BOARD
CN701
E
4
2
3
1
31
45
56 29
128
RF BOARD
CN002
A
1-684-998-
12
1 2 3 4 5 6 7 8 9 10 11
A
B
C
D
E
F
G
H
I
J
K
L
C411
JW303
JW305
1-9. PRINTED WIRING BOARD – MB Board (Component Side) –
• Semiconductor
Location
Ref. No. Location
D201 B-10
IC206 F-10
IC215 H-8
IC401 C-4
IC509 J-4
IC701 J-9
IC801 E-4
IC901 H-5
IC902 F-7
IC904 F-7
IC906 E-6
Q903 B-3
Q904 B-3
