17
HCD-FL7D
3-13. DVD MECHANISM DECK (CDM53N-DVBU14)
3-12. DSP BOARD
1
wire (flat type) (9 core
(CN603)
4
two screws
(BVTP3
×
8)
5
DSP boar
2
wire (flat type) (19 core)
(CN602)
3
wire (flat type) (11 core)
(CN601)
2
two screws
(BVTP 3
×
8)
1
two screws
(BVTP 3
×
8)
3
bracket top panel
7
chassis (CDM) section
6
5
wire (flat type) (29core)
(CN501)
4
four screws
(BVTP 3
×
8)
8
DVD mechanism deck
(CDM53N-DVBU14)
