Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
146
HCD-FL7D
C493 1-128-550-11 ELECT 2200uF 20% 50V
(EXCEPT MX)
C493 1-137-839-11 ELECT 2200uF 20% 50V
(MX)
C494 1-128-550-11 ELECT 2200uF 20% 50V
(EXCEPT MX)
C494 1-137-839-11 ELECT 2200uF 20% 50V
(MX)
C495 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, UK, KR)
< CONNECTOR >
CN402 1-774-743-21 CONNECTOR, BOARD TO BOARD 18P
< DIODE >
D401 8-719-911-19 DIODE 1SS133T-72
D402 8-719-911-19 DIODE 1SS133T-72
D421 8-719-911-19 DIODE 1SS133T-72
D431 8-719-911-19 DIODE 1SS133T-72
D432 8-719-911-19 DIODE 1SS133T-72
D451 8-719-911-19 DIODE 1SS133T-72
D452 8-719-911-19 DIODE 1SS133T-72
D481 8-719-911-19 DIODE 1SS133T-72
D482 8-719-911-19 DIODE 1SS133T-72
D491 6-500-249-01 DIODE D15XB20 (EA, MX, SP, KR)
D491 6-500-250-01 DIODE D15XB20-4001 (US, CND, AEP, UK)
< GROUND TERMINAL >
EP401 1-537-738-21 TERMINAL, GROUND (AEP, UK, KR)
EP402 1-537-738-21 TERMINAL, GROUND (AEP, UK, KR)
< IC >
IC401 8-749-016-93 IC STK402-070S
IC431 8-749-016-93 IC STK402-070S
< TRANSISTOR >
Q401 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q419 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q420 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q421 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q422 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q423 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q431 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q451 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q471 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q472 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q481 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R401 1-249-417-11 CARBON 1K 5% 1/4W
R402 1-249-437-11 CARBON 47K 5% 1/4W
R403 1-249-413-11 CARBON 470 5% 1/4W
R404 1-249-437-11 CARBON 47K 5% 1/4W
0R405 1-208-602-11 METAL 0.22 2W F
0R406 1-208-602-11 METAL 0.22 2W F
R407 1-249-417-11 CARBON 1K 5% 1/4W
R408 1-249-431-11 CARBON 15K 5% 1/4W
R410 1-249-393-11 CARBON 10 5% 1/4W
0R411 1-212-881-11 FUSIBLE 100 5% 1/4W F
0R412 1-212-881-11 FUSIBLE 100 5% 1/4W F
R416 1-249-441-11 CARBON 100K 5% 1/4W
R417 1-249-441-11 CARBON 100K 5% 1/4W
R418 1-249-438-11 CARBON 56K 5% 1/4W
(US, CND, AEP, UK)
R418 1-249-440-11 CARBON 82K 5% 1/4W
(EA, MX, SP, KR)
R419 1-249-429-11 CARBON 10K 5% 1/4W
0R420 1-202-972-61 FUSIBLE 1 5% 1/4W F
R421 1-249-421-11 CARBON 2.2K 5% 1/4W
R422 1-249-433-11 CARBON 22K 5% 1/4W
R423 1-249-439-11 CARBON 68K 5% 1/4W
R424 1-249-426-11 CARBON 5.6K 5% 1/4W
R425 1-249-421-11 CARBON 2.2K 5% 1/4W
R426 1-249-421-11 CARBON 2.2K 5% 1/4W
R427 1-249-435-11 CARBON 33K 5% 1/4W
R428 1-249-431-11 CARBON 15K 5% 1/4W
R431 1-249-417-11 CARBON 1K 5% 1/4W
R432 1-249-437-11 CARBON 47K 5% 1/4W
R433 1-249-415-11 CARBON 680 5% 1/4W
R434 1-249-437-11 CARBON 47K 5% 1/4W
0R435 1-208-602-11 METAL 0.22 2W F
0R436 1-208-602-11 METAL 0.22 2W F
R437 1-249-417-11 CARBON 1K 5% 1/4W
R438 1-249-433-11 CARBON 22K 5% 1/4W
R440 1-249-393-11 CARBON 10 5% 1/4W
R451 1-249-417-11 CARBON 1K 5% 1/4W
R452 1-249-437-11 CARBON 47K 5% 1/4W
R453 1-249-413-11 CARBON 470 5% 1/4W
R454 1-249-437-11 CARBON 47K 5% 1/4W
0R455 1-208-602-11 METAL 0.22 2W F
0R456 1-208-602-11 METAL 0.22 2W F
R457 1-249-417-11 CARBON 1K 5% 1/4W
R458 1-249-431-11 CARBON 15K 5% 1/4W
R460 1-249-393-11 CARBON 10 5% 1/4W
0R461 1-212-881-11 FUSIBLE 100 5% 1/4W F
0R462 1-212-881-11 FUSIBLE 100 5% 1/4W F
R469 1-249-429-11 CARBON 10K 5% 1/4W
0R470 1-202-972-61 FUSIBLE 1 5% 1/4W F
R471 1-249-421-11 CARBON 2.2K 5% 1/4W
R472 1-249-433-11 CARBON 22K 5% 1/4W
R473 1-249-439-11 CARBON 68K 5% 1/4W
R474 1-249-426-11 CARBON 5.6K 5% 1/4W
R475 1-249-421-11 CARBON 2.2K 5% 1/4W
R476 1-249-421-11 CARBON 2.2K 5% 1/4W
R481 1-249-417-11 CARBON 1K 5% 1/4W
R482 1-249-437-11 CARBON 47K 5% 1/4W
R483 1-249-415-11 CARBON 680 5% 1/4W
R484 1-208-602-11 CARBON 47K 5% 1/4W
0R485 1-208-602-11 METAL 0.22 2W F
0R486 1-208-602-11 METAL 0.22 2W F
R487 1-249-417-11 CARBON 1K 5% 1/4W
R488 1-249-433-11 CARBON 22K 5% 1/4W
R490 1-249-393-11 CARBON 10 5% 1/4W
R491 1-249-441-11 CARBON 100K 5% 1/4W
(MX)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
FRONT REAR AMP
