Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
162
HCD-FL7D
FB843 1-410-397-21 FERRITE BEAD, INDUCTOR
< IC >
IC1 6-702-130-01 IC HA12237F
IC2 8-759-143-54 IC uPC1330HA
IC3 8-759-100-96 IC NJM4558M-T1
IC840 6-700-813-01 IC SI-8033JF
< SHORT >
JR800 1-216-864-11 SHORT CHIP 0
JR805 1-216-864-11 SHORT CHIP 0
JR807 1-216-864-11 SHORT CHIP 0
JR808 1-216-864-11 SHORT CHIP 0
JR811 1-216-864-11 SHORT CHIP 0
JR815 1-216-864-11 SHORT CHIP 0
< COIL >
L21 1-410-780-11 INDUCTOR 27mH
L40 1-414-193-41 INDUCTOR 220uH
L41 1-414-193-41 INDUCTOR 220uH
L71 1-410-780-11 INDUCTOR 27mH
L801 1-422-009-13 COIL, AIR-CORE (AEP, UK, KR)
L802 1-422-009-13 COIL, AIR-CORE (AEP, UK, KR)
L803 1-422-009-13 COIL, AIR-CORE (AEP, UK, KR)
L804 1-422-009-13 COIL, AIR-CORE (AEP, UK, KR)
L805 1-422-009-13 COIL, AIR-CORE (AEP, UK, KR)
L806 1-422-009-13 COIL, AIR-CORE (AEP, UK, KR)
L807 1-422-009-13 COIL, AIR-CORE (KR)
L808 1-422-009-13 COIL, AIR-CORE (KR)
L809 1-422-009-13 COIL, AIR-CORE (KR)
L840 1-419-253-11 INDUCTOR 100uH
L841 1-414-398-11 INDUCTOR 10uH
L842 1-414-398-11 INDUCTOR 10uH
< TRANSISTOR >
Q2 8-729-801-93 TRANSISTOR 2SD1387-34-TP
Q3 8-729-116-02 TRANSISTOR BA1A4M-TP
Q4 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q5 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q6 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q7 8-729-116-02 TRANSISTOR BA1A4M-TP
Q8 8-729-116-02 TRANSISTOR BA1A4M-TP
Q9 8-729-040-20 TRANSISTOR RT1P137L-TP
Q20 8-729-900-63 TRANSISTOR BN1F4M-TP
Q21 8-729-116-02 TRANSISTOR BA1A4M-TP
Q40 8-729-116-02 TRANSISTOR BA1A4M-TP
Q41 8-729-116-02 TRANSISTOR BA1A4M-TP
Q801 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q802 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
(EA, MX, SP, KR)
Q803 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
(EA, MX, SP, KR)
Q804 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q805 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q806 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
(EA, MX, SP, KR)
Q807 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q850 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q851 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q852 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q853 8-729-111-29 TRANSISTOR 2SD1616A-TP-LK
Q854 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q855 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q856 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q860 8-729-116-02 TRANSISTOR BA1A4M-TP
Q861 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q862 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q863 8-729-026-68 TRANSISTOR 2SD2525 (TP)
Q870 8-729-116-02 TRANSISTOR BA1A4M-TP
Q871 8-729-116-02 TRANSISTOR BA1A4M-TP
< RESISTOR >
R1 1-216-827-11 RES-CHIP 3.3K 5% 1/10W
R2 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R4 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R5 1-216-841-11 RES-CHIP 47K 5% 1/10W
R7 1-216-833-11 RES-CHIP 10K 5% 1/10W
R8 1-216-825-11 RES-CHIP 2.2K 5% 1/10W
R10 1-216-841-11 RES-CHIP 47K 5% 1/10W
R11 1-216-809-11 RES-CHIP 100 5% 1/10W
R12 1-216-809-11 RES-CHIP 100 5% 1/10W
R13 1-216-809-11 RES-CHIP 100 5% 1/10W
R14 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R15 1-216-809-11 RES-CHIP 100 5% 1/10W
R17 1-216-857-11 RES-CHIP 1M 5% 1/10W
R18 1-216-832-11 RES-CHIP 8.2K 5% 1/10W
R19 1-216-837-11 RES-CHIP 22K 5% 1/10W
R20 1-216-809-11 RES-CHIP 100 5% 1/10W
R21 1-216-833-11 RES-CHIP 10K 5% 1/10W
R22 1-216-825-11 RES-CHIP 2.2K 5% 1/10W
R23 1-216-809-11 RES-CHIP 100 5% 1/10W
R25 1-216-825-11 RES-CHIP 2.2K 5% 1/10W
R26 1-216-827-11 RES-CHIP 3.3K 5% 1/10W
R27 1-216-836-11 RES-CHIP 18K 5% 1/10W
R28 1-216-836-11 RES-CHIP 18K 5% 1/10W
0R29 1-219-787-17 FUSIBLE 5.6 5% 1/4W F
0R30 1-219-787-17 FUSIBLE 5.6 5% 1/4W F
R31 1-216-837-11 RES-CHIP 22K 5% 1/10W
R32 1-216-813-11 RES-CHIP 220 5% 1/10W
R33 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R34 1-216-825-11 RES-CHIP 2.2K 5% 1/10W
R35 1-216-845-11 RES-CHIP 100K 5% 1/10W
R36 1-216-833-11 RES-CHIP 10K 5% 1/10W
R39 1-216-833-11 RES-CHIP 10K 5% 1/10W
R40 1-216-833-11 RES-CHIP 10K 5% 1/10W
R41 1-216-821-11 RES-CHIP 1K 5% 1/10W
R42 1-216-821-11 RES-CHIP 1K 5% 1/10W
R43 1-216-861-11 RES-CHIP 2.2M 5% 1/10W
R44 1-216-835-11 RES-CHIP 15K 5% 1/10W
R45 1-216-835-11 RES-CHIP 15K 5% 1/10W
R46 1-216-833-11 RES-CHIP 10K 5% 1/10W
R47 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R48 1-216-837-11 RES-CHIP 22K 5% 1/10W
R49 1-216-833-11 RES-CHIP 10K 5% 1/10W
R50 1-216-833-11 RES-CHIP 10K 5% 1/10W
SP RELAY
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
