Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
33
HCD-FL7D
PANEL (L) PANEL (R) TC DOOR
A-4676-820-A PANEL (L) BOARD, COMPLETE (US, CND)
A-4728-401-A PANEL (L) BOARD, COMPLETE
(EA, MX, SP, KR)
A-4731-210-A PANEL (L) BOARD, COMPLETE (AEP, UK)
*************************
< CAPACITOR >
C301 1-126-947-11 ELECT 47uF 20% 10V
< LED >
D301 8-719-058-04 LED SEL5223S-TP15 (\/1)
(EXCEPT AEP, UK)
D301 8-719-071-44 LED SELS5223C-TP15 (\/1) (AEP, UK)
D302 8-719-071-41 LED SELS5923C-TP15 (DVD)
D303 8-719-071-41 LED SELS5923C-TP15 (TUNER/BAND)
D304 8-719-071-41 LED SELS5923C-TP15 (TAPE A/B)
< IC >
IC301 6-600-071-01 IC TSOP7000
< RESISTOR >
R301 1-216-813-11 RES-CHIP 220 5% 1/10W
(EXCEPT AEP, UK)
R301 1-216-821-11 RES-CHIP 1K 5% 1/10W
(AEP, UK)
R302 1-216-809-11 RES-CHIP 100 5% 1/10W
R303 1-216-809-11 RES-CHIP 100 5% 1/10W
R304 1-216-809-11 RES-CHIP 100 5% 1/10W
R305 1-216-819-11 RES-CHIP 680 5% 1/10W
R306 1-216-821-11 RES-CHIP 1K 5% 1/10W
R307 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
R308 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
R309 1-216-825-11 RES-CHIP 2.2K 5% 1/10W
R310 1-216-827-11 RES-CHIP 3.3K 5% 1/10W
(US, CND, AEP, UK)
R311 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
(US, CND, AEP, UK)
R312 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
(US, CND, AEP, UK)
R313 1-216-805-11 RES-CHIP 47 5% 1/10W
R314 1-216-805-11 RES-CHIP 47 5% 1/10W
< SWITCH >
S301 1-771-410-21 SWITCH, TACTILE (\/1)
S302 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S303 1-771-410-21 SWITCH, TACTILE (DVD)
S304 1-771-410-21 SWITCH, TACTILE (TUNER/BAND)
S305 1-771-410-21 SWITCH, TACTILE (TAPE A/B)
S306 1-771-410-21 SWITCH, TACTILE (DIGITAL)
S307 1-771-410-21 SWITCH, TACTILE (MD (VIDEO))
(EXCEPT US, CND)
S307 1-771-410-21 SWITCH, TACTILE (VIDEO (MD)) (US, CND)
S308 1-771-410-21 SWITCH, TACTILE (GROOVE)
(US, CND, AEP, UK)
S309 1-771-410-21 SWITCH, TACTILE (EFFECT)
(US, CND, AEP, UK)
S310 1-771-410-21 SWITCH, TACTILE (2.1CH/MULTI)
(US, CND, AEP, UK)
**************************************************************
A-4728-403-A PANEL (R) BOARD, COMPLETE
****************
< CAPACITOR >
C313 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< JACK >
J301 1-815-603-11 JACK (PHONES)
< RESISTOR >
R321 1-216-819-11 RES-CHIP 680 5% 1/10W
R322 1-216-821-11 RES-CHIP 1K 5% 1/10W
R323 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
R324 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
R325 1-216-825-11 RES-CHIP 2.2K 5% 1/10W
R326 1-216-827-11 RES-CHIP 3.3K 5% 1/10W
R327 1-216-829-11 RES-CHIP 4.7K 5% 1/10W
R328 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R329 1-216-819-11 RES-CHIP 680 5% 1/10W
R330 1-216-821-11 RES-CHIP 1K 5% 1/10W
R331 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
R332 1-216-823-11 RES-CHIP 1.5K 5% 1/10W
< SWITCH >
S311 1-771-410-21 SWITCH, TACTILE (DISC SELECT)
S312 1-771-410-21 SWITCH, TACTILE (Z)
S313 1-771-410-21 SWITCH, TACTILE (gG)
S314 1-771-410-21 SWITCH, TACTILE (X)
S315 1-771-410-21 SWITCH, TACTILE (x)
S316 1-771-410-21 SWITCH, TACTILE (.)
S317 1-771-410-21 SWITCH, TACTILE (>)
S318 1-771-410-21 SWITCH, TACTILE (– m)
S319 1-771-410-21 SWITCH, TACTILE (M +)
S320 1-771-410-21 SWITCH, TACTILE (DVD TOP MENU)
S321 1-771-410-21 SWITCH, TACTILE (DVD MENU)
S322 1-771-410-21 SWITCH, TACTILE (CD SYNC, HI-DUB)
S323 1-771-410-21 SWITCH, TACTILE (REC, PAUSE/START)
S324 1-771-410-21 SWITCH, TACTILE (Z B)
**************************************************************
1-684-198-11 TC DOOR BOARD
**************
< CONNECTOR >
CN319 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< DIODE >
D309 8-719-988-61 DIODE 1SS355TE-17
D310 8-719-988-61 DIODE 1SS355TE-17
< SHORT >
JR214 1-216-864-11 SHORT CHIP 0
**************************************************************
