HCD-FL7D
5757
1.6 Vp-p
50 ns
Approx.
50 mVp-p
Approx.
1.2 Vp-p
Approx.
100 mVp-p
• Waveforms
– RF Board –
1 IC001 1 (DVDRFP)
Approx.
1.2 Vp-p
Approx.
50 mVp-p
Approx.
100 mVp-p
Approx.
400 mVp-p
3 IC001 r; (FE)
4 IC001 tj (RFAC)
2 IC001 el (TE)
Approx.
50 mVp-p
3.4 Vp-p
40.8 µs
qs IC509 el (FE)
qd IC509 ra (TE)
– MB Board –
qa IC509 0 (WFCK)
qf IC401 t; (RFAC)
3.4 Vp-p
6.8 µs
qg IC509 yg (LRCK)
qh IC509 yj (BCK)
4.5 Vp-p
142 ns
Approx.
1.2 Vp-p
qj IC509 ua (XTAI)
qk IC701 <zzm (RFIN)
ql IC701 <zbz (WFCK)
3.4 Vp-p
40.8 µs
4.5 Vp-p
142 ns
w; IC701 <zb, (BCLK)
4.5 Vp-p
29.5 ns
wa IC701 <znc (LRCK)
3.4 Vp-p
6.8 µs
4.6 Vp-p
44 ns
ws IC701 <znm (XTAL)
wd IC801 qa (MCKI)
wf IC801 qd (EXCKO1)
4.6 Vp-p
354 ns
wg IC801 ys (PHREFO)
4.7 Vp-p
29.5 ns
5 Vp-p
29.5 ns
Approx.
100 mVp-p
wj IC901 yg (TE)
wk IC901 yj (FE)
wh IC901 ra (EXTAL)
wl IC906 3 (MO1)
3.8 Vp-p
37 ns
e; IC906 8 (XTO)
4.2 Vp-p
37 ns
750 mVp-p
H
680 mVp-p
H
710 mVp-p
H
1.1 Vp-p
H
es IC206 <zxx (VDAC 3) (NTSC Color Bars Play)
ed IC206 <zxb (VDAC 2) (NTSC Color Bars Play)
ea IC206 <zz. (VDAC 4) (NTSC Color Bars Play)
ef IC206 <zx, (VDAC 1) (NTSC Color Bars Play)
1.2 Vp-p
H
eg IC206 <zcz (VDAC 0) (NTSC Color Bars Play)
eh IC206 <zc. (XIN)
4.3 Vp-p
37 ns
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
