Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
129
HCD-M90
R524 1-216-817-11 METAL CHIP 470 5% 1/10W
R525 1-216-819-11 METAL CHIP 680 5% 1/10W
R526 1-216-821-11 METAL CHIP 1K 5% 1/10W
R527 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R530 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R531 1-216-817-11 METAL CHIP 470 5% 1/10W
R534 1-216-809-11 METAL CHIP 100 5% 1/10W
R535 1-216-809-11 METAL CHIP 100 5% 1/10W
R536 1-216-809-11 METAL CHIP 100 5% 1/10W
R537 1-216-809-11 METAL CHIP 100 5% 1/10W
R538 1-216-833-11 METAL CHIP 10K 5% 1/10W
R811 1-216-817-11 METAL CHIP 470 5% 1/10W
R812 1-216-817-11 METAL CHIP 470 5% 1/10W
R813 1-216-817-11 METAL CHIP 470 5% 1/10W
R898 1-216-817-11 METAL CHIP 470 5% 1/10W
R899 1-216-817-11 METAL CHIP 470 5% 1/10W
R900 1-216-817-11 METAL CHIP 470 5% 1/10W
< SWITCH >
S801 1-786-220-11 SWITCH, KEY BOARD (Z DVD)
S802 1-786-220-11 SWITCH, KEY BOARD (TAPE Y)
S803 1-571-760-11 SWITCH, KEY BOARD (I/1)
S804 1-786-220-11 SWITCH, KEY BOARD (DVD X)
S805 1-786-220-11 SWITCH, KEY BOARD (TUNER FM)
S806 1-571-760-11 SWITCH, KEY BOARD (FUNCTION)
S807 1-786-220-11 SWITCH, KEY BOARD (DVD N)
S808 1-571-760-11 SWITCH, KEY BOARD (DSG)
S809 1-571-760-11 SWITCH, KEY BOARD (VOLUME –)
S811 1-571-760-11 SWITCH, KEY BOARD (VOLUME +)
S812 1-786-220-11 SWITCH, KEY BOARD (TAPE X)
S813 1-571-760-11 SWITCH, KEY BOARD (x)
S815 1-571-760-11 SWITCH, KEY BOARD (TUNING +, M L)
S817 1-786-220-11 SWITCH, KEY BOARD (z REC)
S818 1-571-760-11 SWITCH, KEY BOARD (TUNING –, l m)
S820 1-786-220-11 SWITCH, KEY BOARD (TUNER AM)
**************************************************************
A-4729-457-A SWITCH BOARD, COMPLETE (EXCEPT CH)
A-4730-561-A SWITCH BOARD, COMPLETE (CH)
***********************
4-240-895-01 SHEET (LCD)
4-240-898-01 PLATE (LCD) , LIGHT
4-240-904-01 HOLDER (LCD)
< CAPACITOR >
C800 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C806 1-126-160-11 ELECT 1uF 20% 50V
C807 1-126-160-11 ELECT 1uF 20% 50V
C820 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C821 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C822 1-124-259-11 ELECT 4.7uF 20% 16V
C833 1-124-584-00 ELECT 100uF 20% 10V
C874 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C875 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN501 1-568-838-11 CONNECTOR, FFC 21P
< LED >
D804 6-500-083-01 LED NSPW315BSRS (LCD BACK LIGHT)
D805 6-500-083-01 LED NSPW315BSRS (LCD BACK LIGHT)
D806 6-500-083-01 LED NSPW315BSRS (LCD BACK LIGHT)
D809 6-500-076-01 LED SLI-343YC (DVD)
D810 6-500-076-01 LED SLI-343YC (TUNER)
D811 6-500-076-01 LED SLI-343YC (DSG)
D812 6-500-076-01 LED SLI-343YC (TAPE)
D813 8-719-074-42 LED SLR325VR-T31 (CD SYNCHRO)
D814 8-719-074-42 LED SLR325VR-T31 (STANDBY)
< IC >
IC802 8-759-826-34 IC NJL74H400A
(REMOTE CONTROL RECEIVER)
<SHORT >
JR501 1-216-864-11 SHORT CHIP 0
JR505 1-216-864-11 SHORT CHIP 0
JR513 1-216-864-11 SHORT CHIP 0
JR521 1-216-864-11 SHORT CHIP 0
JR523 1-216-864-11 SHORT CHIP 0
< COIL >
L501 1-412-006-31 INDUCTOR 10uH
< LIQUID CRYSTAL DISPLAY >
LCD802 1-804-689-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q805 8-729-055-94 TRANSISTOR SRC1202SF
Q806 8-729-055-94 TRANSISTOR SRC1202SF
Q807 8-729-055-94 TRANSISTOR SRC1202SF
Q808 8-729-055-94 TRANSISTOR SRC1202SF
Q809 8-729-055-94 TRANSISTOR SRC1202SF
Q811 8-729-055-94 TRANSISTOR SRC1202SF
Q812 8-729-055-94 TRANSISTOR SRC1202SF
Q813 8-729-055-94 TRANSISTOR SRC1202SF
< RESISTOR >
R501 1-216-818-11 METAL CHIP 560 5% 1/10W
R502 1-216-818-11 METAL CHIP 560 5% 1/10W
R503 1-216-818-11 METAL CHIP 560 5% 1/10W
R504 1-216-818-11 METAL CHIP 560 5% 1/10W
R505 1-216-818-11 METAL CHIP 560 5% 1/10W
R512 1-216-813-11 METAL CHIP 220 5% 1/10W
R513 1-216-815-11 METAL CHIP 330 5% 1/10W
R514 1-216-817-11 METAL CHIP 470 5% 1/10W
R516 1-216-813-11 METAL CHIP 220 5% 1/10W
R517 1-216-815-11 METAL CHIP 330 5% 1/10W
R518 1-216-817-11 METAL CHIP 470 5% 1/10W
R519 1-216-819-11 METAL CHIP 680 5% 1/10W
R520 1-216-821-11 METAL CHIP 1K 5% 1/10W
R521 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R522 1-216-813-11 METAL CHIP 220 5% 1/10W
R523 1-216-815-11 METAL CHIP 330 5% 1/10W
R524 1-216-817-11 METAL CHIP 470 5% 1/10W
R525 1-216-819-11 METAL CHIP 680 5% 1/10W
SWITCH (Suffix-11) SWITCH (Suffix-12)
