Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
130
HCD-M90
R526 1-216-821-11 METAL CHIP 1K 5% 1/10W
R527 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R530 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R531 1-216-821-11 METAL CHIP 1K 5% 1/10W
R534 1-216-809-11 METAL CHIP 100 5% 1/10W
R535 1-216-809-11 METAL CHIP 100 5% 1/10W
R536 1-216-809-11 METAL CHIP 100 5% 1/10W
R537 1-216-809-11 METAL CHIP 100 5% 1/10W
R538 1-216-833-11 METAL CHIP 10K 5% 1/10W
R541 1-216-821-11 METAL CHIP 1K 5% 1/10W
R531 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R811 1-216-817-11 METAL CHIP 470 5% 1/10W
R812 1-216-817-11 METAL CHIP 470 5% 1/10W
R813 1-216-817-11 METAL CHIP 470 5% 1/10W
R898 1-216-817-11 METAL CHIP 470 5% 1/10W
R899 1-216-817-11 METAL CHIP 470 5% 1/10W
R900 1-216-817-11 METAL CHIP 470 5% 1/10W
< SWITCH >
S801 1-786-220-11 SWITCH, KEY BOARD (Z DVD)
S802 1-786-220-11 SWITCH, KEY BOARD (TAPE Y)
S803 1-571-760-11 SWITCH, KEY BOARD (I/1)
S804 1-786-220-11 SWITCH, KEY BOARD (DVD X)
S805 1-786-220-11 SWITCH, KEY BOARD (TUNER FM)
S806 1-571-760-11 SWITCH, KEY BOARD (FUNCTION)
S807 1-786-220-11 SWITCH, KEY BOARD (DVD N)
S808 1-571-760-11 SWITCH, KEY BOARD (DSG)
S809 1-571-760-11 SWITCH, KEY BOARD (VOLUME –)
S811 1-571-760-11 SWITCH, KEY BOARD (VOLUME +)
S812 1-786-220-11 SWITCH, KEY BOARD (TAPE X)
S813 1-571-760-11 SWITCH, KEY BOARD (x)
S815 1-571-760-11 SWITCH, KEY BOARD (TUNING +, M L)
S817 1-786-220-11 SWITCH, KEY BOARD (z REC)
S818 1-571-760-11 SWITCH, KEY BOARD (TUNING –, l m)
S820 1-786-220-11 SWITCH, KEY BOARD (TUNER AM)
**************************************************************
A-4729-461-A TC BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C102 1-126-947-11 ELECT 47uF 20% 16V
C104 1-130-483-00 MYLAR 0.01uF 5% 50V
C105 1-126-960-11 ELECT 1uF 20% 50V
C106 1-126-964-11 ELECT 10uF 20% 50V
C107 1-126-960-11 ELECT 1uF 20% 50V
C108 1-126-961-11 ELECT 2.2uF 20% 50V
C109 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C110 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C111 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C201 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C202 1-126-947-11 ELECT 47uF 20% 16V
C204 1-130-483-00 MYLAR 0.01uF 5% 50V
C205 1-126-960-11 ELECT 1uF 20% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-126-960-11 ELECT 1uF 20% 50V
C208 1-126-961-11 ELECT 2.2uF 20% 50V
C209 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C210 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C211 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C400 1-126-964-11 ELECT 10uF 20% 50V
C401 1-126-933-11 ELECT 100uF 20% 16V
C402 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C403 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C407 1-126-964-11 ELECT 10uF 20% 50V
C410 1-126-960-11 ELECT 1uF 20% 50V
C422 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C432 1-136-967-11 MYLAR 0.012uF 5% 50V
C433 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C434 1-126-947-11 ELECT 47uF 20% 10V
C435 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C437 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN301 1-784-778-11 CONNECTOR, FFC 17P
CN302 1-691-040-31 CONNECTOR, FFC 8P
< SHORT >
D401 1-216-864-11 SHORT CHIP 0
< IC >
IC401 6-701-655-01 IC HA12236F
< RESISTOR >
JR102 1-216-864-11 SHORT CHIP 0
JR103 1-216-864-11 SHORT CHIP 0
JR104 1-216-864-11 SHORT CHIP 0
JR105 1-216-821-11 METAL CHIP 1K 5% 1/10W
JR106 1-216-821-11 METAL CHIP 1K 5% 1/10W
JR201 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q100 8-729-212-02 TRANSISTOR 2SC2120-Y
Q101 8-729-212-02 TRANSISTOR 2SC2120-Y
Q200 8-729-212-02 TRANSISTOR 2SC2120-Y
Q201 8-729-212-02 TRANSISTOR 2SC2120-Y
Q401 8-729-212-02 TRANSISTOR 2SC2120-Y
Q402 8-729-037-02 TRANSISTOR 2SC2120-Y
Q403 8-729-038-67 TRANSISTOR KRC102S
Q404 8-759-068-54 TRANSISTOR WSC57C291B-RE20A
Q405 8-729-038-71 TRANSISTOR KRC107S
< RESISTOR >
R101 1-216-841-11 METAL CHIP 47K 5% 1/10W
R102 1-216-841-11 METAL CHIP 47K 5% 1/10W
R103 1-216-833-11 METAL CHIP 10K 5% 1/10W
R104 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R105 1-216-841-11 METAL CHIP 47K 5% 1/10W
R106 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-833-11 METAL CHIP 10K 5% 1/10W
R109 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R111 1-216-833-11 METAL CHIP 10K 5% 1/10W
SWITCH (Suffix-12) TC (Suffix-12)
Ver 1.3
