Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
131
HCD-M90
R112 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R113 1-216-797-11 METAL CHIP 10 5% 1/10W
R201 1-216-841-11 METAL CHIP 47K 5% 1/10W
R202 1-216-841-11 METAL CHIP 47K 5% 1/10W
R203 1-216-833-11 METAL CHIP 10K 5% 1/10W
R204 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R205 1-216-841-11 METAL CHIP 47K 5% 1/10W
R206 1-216-833-11 METAL CHIP 10K 5% 1/10W
R207 1-216-833-11 METAL CHIP 10K 5% 1/10W
R208 1-216-833-11 METAL CHIP 10K 5% 1/10W
R209 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R211 1-216-833-11 METAL CHIP 10K 5% 1/10W
R212 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R213 1-216-797-11 METAL CHIP 10 5% 1/10W
R400 1-218-446-11 METAL CHIP 1 5% 1/10W
R401 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R402 1-216-797-11 METAL CHIP 10 5% 1/10W
R403 1-216-805-11 METAL CHIP 47 5% 1/10W
R404 1-216-833-11 METAL CHIP 10K 5% 1/10W
R405 1-216-797-11 METAL CHIP 10 5% 1/10W
R406 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R407 1-216-841-11 METAL CHIP 47K 5% 1/10W
R408 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R409 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R410 1-216-833-11 METAL CHIP 10K 5% 1/10W
R411 1-216-841-11 METAL CHIP 47K 5% 1/10W
R412 1-216-833-11 METAL CHIP 10K 5% 1/10W
R413 1-216-857-11 METAL CHIP 1M 5% 1/10W
R414 1-216-803-11 METAL CHIP 33 5% 1/10W
R415 1-216-841-11 METAL CHIP 47K 5% 1/10W
R416 1-216-821-11 METAL CHIP 1K 5% 1/10W
R417 1-218-725-11 METAL CHIP 24K 5% 1/10W
R418 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R422 1-216-833-11 METAL CHIP 10K 5% 1/10W
R423 1-216-837-11 METAL CHIP 22K 5% 1/10W
R424 1-216-841-11 METAL CHIP 47K 5% 1/10W
R425 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R426 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R428 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< VARIABLE RESISTOR >
RV101 1-225-282-21 RES, ADJ, CARBON 33K
RV201 1-225-282-21 RES, ADJ, CARBON 33K
< COIL/TRANSFORMER >
T101 1-419-080-11 COIL
T201 1-419-080-11 COIL
T401 1-433-372-31 TRANSFORMER, BIAS OSCILLATION
< TERMINAL >
TH1 1-537-770-21 TERMINAL BOARD, GROUND
TH2 1-537-770-21 TERMINAL BOARD, GROUND
TH3 1-537-770-21 TERMINAL BOARD, GROUND
**************************************************************
A-4729-461-A TC BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C102 1-126-947-11 ELECT 47uF 20% 16V
C104 1-130-483-00 MYLAR 0.01uF 5% 50V
C105 1-126-960-11 ELECT 1uF 20% 50V
C106 1-126-964-11 ELECT 10uF 20% 50V
C107 1-126-960-11 ELECT 1uF 20% 50V
C108 1-126-961-11 ELECT 2.2uF 20% 50V
C109 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C110 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C111 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C201 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C202 1-126-947-11 ELECT 47uF 20% 16V
C204 1-130-483-00 MYLAR 0.01uF 5% 50V
C205 1-126-960-11 ELECT 1uF 20% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-126-960-11 ELECT 1uF 20% 50V
C208 1-126-961-11 ELECT 2.2uF 20% 50V
C209 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C210 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C211 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C400 1-126-964-11 ELECT 10uF 20% 50V
C401 1-126-933-11 ELECT 100uF 20% 16V
C402 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C403 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C407 1-126-964-11 ELECT 10uF 20% 50V
C410 1-126-960-11 ELECT 1uF 20% 50V
C422 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C432 1-136-967-11 MYLAR 0.012uF 5% 50V
C433 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C434 1-126-947-11 ELECT 47uF 20% 10V
C435 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C437 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN301 1-784-778-11 CONNECTOR, FFC 17P
CN302 1-691-040-31 CONNECTOR, FFC 8P
< IC >
IC401 6-702-130-01 IC HA12237F
< RESISTOR >
JR102 1-216-864-11 SHORT CHIP 0
JR103 1-216-864-11 SHORT CHIP 0
JR104 1-216-864-11 SHORT CHIP 0
JR105 1-216-821-11 METAL CHIP 1K 5% 1/10W
JR106 1-216-821-11 METAL CHIP 1K 5% 1/10W
JR201 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q100 8-729-212-02 TRANSISTOR 2SC2120-Y
Q101 8-729-212-02 TRANSISTOR 2SC2120-Y
Q200 8-729-212-02 TRANSISTOR 2SC2120-Y
Q201 8-729-212-02 TRANSISTOR 2SC2120-Y
TC (Suffix-12) TC (Suffix-32)
