Sony MHC-V6D Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MHC-V6D
100
C1661 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
< CONNECTOR >
CN1000 1-779-092-11 PIN, CONNECTOR (PC BOARD) 10P
CN1003 1-564-506-11 PLUG, CONNECTOR 3P
CN1006 1-820-117-41 CONNECTOR, FFC/FPC 19P
CN1008 1-564-320-00 PIN, CONNECTOR (3.96 mm PITCH) 2P
CN1009 1-564-321-00 PIN, CONNECTOR (3.96 mm PITCH) 2P
* CN1010 1-564-104-00 PIN, CONNECTOR (3.96 mm PITCH) 3P
< DIODE >
D1000 6-503-857-01 DIODE BAW56
D1001 6-500-514-01 DIODE BAV70
D1002 6-502-970-01 DIODE DZ2J068M0L
D1003 6-502-970-01 DIODE DZ2J068M0L
D1004 6-503-026-01 DIODE DZ2J120M0L
D1005 6-503-026-01 DIODE DZ2J120M0L
D1006 6-502-970-01 DIODE DZ2J068M0L
D1007 6-502-974-01 DIODE DZ2J140M0L
D1008 6-502-970-01 DIODE DZ2J068M0L
D1009 6-500-514-01 DIODE BAV70
D1010 6-503-857-01 DIODE BAW56
D1024 6-503-857-01 DIODE BAW56
D1025 6-503-987-01 DIODE RF05VAM2STR
D1026 6-503-987-01 DIODE RF05VAM2STR
D1027 6-502-759-01 DIODE RF201L2STE25
D1028 6-502-759-01 DIODE RF201L2STE25
D1029 6-503-987-01 DIODE RF05VAM2STR
D1030 6-503-987-01 DIODE RF05VAM2STR
D1031 6-502-759-01 DIODE RF201L2STE25
D1032 6-502-759-01 DIODE RF201L2STE25
D1034 6-503-857-01 DIODE BAW56
D1035 6-503-987-01 DIODE RF05VAM2STR
D1036 6-503-987-01 DIODE RF05VAM2STR
D1037 6-502-759-01 DIODE RF201L2STE25
D1038 6-502-759-01 DIODE RF201L2STE25
D1051 8-719-073-35 DIODE RB551V-30TE-17
D1061 6-500-514-01 DIODE BAV70
< LUG TERMINAL >
* ET1000 1-780-408-11 TERMINAL, LUG (Suffi x-11) (See Note)
* ET1001 1-780-408-11 TERMINAL, LUG (Suffi x-11) (See Note)
< IC >
IC1000 6-717-138-01 IC KIA7805AF-RTF/PW
IC1001 6-717-136-01 IC KIA7905F-RTF/PW
IC1002 6-717-191-01 IC KIA7812AF-RTF/PW
IC1003 6-717-488-01 IC BA4580RF-E2
IC1009 6-720-389-01 IC IRS2092STRPBF-CU
IC1011 6-720-389-01 IC IRS2092STRPBF-CU
IC1012 6-720-389-01 IC IRS2092STRPBF-CU
IC1015 8-759-700-09 IC NJM2043M-D
IC1016 8-759-700-09 IC NJM2043M-D
< JUMPER RESISTOR >
JC1032 1-216-864-11 SHORT CHIP 0 (Suffi x-11) (See Note)
JC1061 1-216-864-11 SHORT CHIP 0 (Suffi x-11) (See Note)
JC1063 1-216-864-11 SHORT CHIP 0 (Suffi x-11) (See Note)
< COIL >
L1000 1-400-922-11 INDUCTOR 220uH
L1011 1-482-160-21 INDUCTOR 20uH
L1012 1-420-872-71 COIL, AIR-CORE
L1014 1-482-160-21 INDUCTOR 20uH
L1015 1-420-872-71 COIL, AIR-CORE
L1017 1-482-160-21 INDUCTOR 20uH
L1018 1-420-872-71 COIL, AIR-CORE
< TRANSISTOR >
Q1000 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q1002 8-729-905-35 TRANSISTOR 2SC4081-R
Q1003 6-552-922-01 TRANSISTOR LTA014EUBFS8TL
Q1004 8-729-924-99 TRANSISTOR 2SC3722K-E
Q1005 6-552-746-01 TRANSISTOR DSA700300L
Q1006 8-729-056-46 TRANSISTOR 2SC5053T100Q
Q1007 6-550-978-01 TRANSISTOR RN1902
Q1008 6-551-039-01 TRANSISTOR RN4902 (T5RSONY, D, F)
Q1023 6-552-698-01 FET IRF6775MTR1PBF
Q1025 6-552-698-01 FET IRF6775MTR1PBF
Q1026 8-729-013-28 TRANSISTOR HN1B01FU
Q1027 8-729-427-72 TRANSISTOR XP4501
Q1028 6-552-698-01 FET IRF6775MTR1PBF
Q1030 6-552-698-01 FET IRF6775MTR1PBF
Q1031 8-729-013-28 TRANSISTOR HN1B01FU
Q1032 6-552-698-01 FET IRF6775MTR1PBF
Q1033 8-729-023-22 TRANSISTOR 2SD2114K
Q1034 6-552-698-01 FET IRF6775MTR1PBF
Q1035 8-729-023-22 TRANSISTOR 2SD2114K
Q1036 8-729-013-28 TRANSISTOR HN1B01FU
Q1037 8-729-427-72 TRANSISTOR XP4501
Q1042 8-729-023-22 TRANSISTOR 2SD2114K
Q1058 6-550-978-01 TRANSISTOR RN1902
Q1059 6-552-746-01 TRANSISTOR DSA700300L
Q1060 8-729-013-28 TRANSISTOR HN1B01FU
Q1062 8-729-924-99 TRANSISTOR 2SC3722K-E
Q1065 8-729-427-72 TRANSISTOR XP4501
Q1066 8-729-924-99 TRANSISTOR 2SC3722K-E
Q1067 6-552-891-01 TRANSISTOR LSAR523UBFS8TL
Q1069 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q1070 6-552-746-01 TRANSISTOR DSA700300L
Q1071 6-552-892-01 TRANSISTOR LSCR523UBFS8TL
< RESISTOR >
R1000 1-257-362-21 METAL CHIP 1 5% 1/2W
R1001 1-216-846-11 METAL CHIP 120K 5% 1/10W
R1002 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1003 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1004 1-216-846-11 METAL CHIP 120K 5% 1/10W
R1005 1-216-848-11 METAL CHIP 180K 5% 1/10W
R1006 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1007 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1008 1-216-848-11 METAL CHIP 180K 5% 1/10W
R1009 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R1010 1-257-362-21 METAL CHIP 1 5% 1/2W
R1011 1-216-864-11 SHORT CHIP 0 (Suffi x-11) (See Note)
R1013 1-216-864-11 SHORT CHIP 0 (Suffi x-11) (See Note)
R1017 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R1018 1-227-869-21 METAL CHIP 100 5% 1/2W
Note: Refer to the “NEW/FORMER DISCRIMINATION OF D-AMP
AND SPEAKER LED BOARDS” on page 4 for how to distinguish
suffi x-11 of D-AMP board.
D-AMP

Sony MHC-V6D Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
Impedance	5 Ω
Bass reflex	-
Speaker type	3-way
RMS rated power	1440 W
Woofer diameter	250 mm
Tweeter diameter	40 mm
Number of speakers	5
Mid-range driver diameter	100 mm
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Display type	LCD
Audio (L/R) in	1
USB 2.0 ports quantity	2
Analog signal format system	NTSC, PAL
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	ENG, CHI (SIMPL), THA, CHI (TR)
Disc types supported	CD-RW, DVD-R, DVD, CD, DVD+R, DVD+R DL, CD-R, DVD+RW, DVD-RW
Audio formats supported	WMA, MP3
Power source	AC
Input voltage	120-240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Equalizer modes	Custom, Pop, Flat, Rap, Rock

Weight and Dimensions

Depth	325 mm
Width	339 mm
Height	908 mm
Weight	18000 g
Package depth	417 mm
Package width	972 mm
Package height	381 mm
Package weight	21000 g
