6-7. TOP PANEL SECTION
• Bottom view
301 4-484-646-02 KNOB, VOLUME
302 X-2588-879-2 PANEL, TOP ASSY
303 3-831-441-11 CUSHION, SPEAKER GRILLE (FAB-NW)
(See Note)
#2 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
302
303
303
303
303
303
303
303
303
303
303
303
303
303
303
303
303
303
303
301
not supplied
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
#2
not supplied
(TOP KEY A board)
not supplied
(TOP KEY B board)
not supplied
(HOLD board)
5 mm
5 mm
Note:
When replacing the Ref. No. 303
for new part, cut out and use it
for a specified size.
