Sony MHC-V6D Service Manual

90
MHC-V6D
SECTION 7
ELECTRICAL PARTS LIST
A-2057-795-A ARAGON BOARD, COMPLETE (for SERVICE)
(E4)
A-2057-796-A ARAGON BOARD, COMPLETE (for SERVICE)
(IND)
A-2057-797-A ARAGON BOARD, COMPLETE (for SERVICE)
(SAF)
A-2057-798-A ARAGON BOARD, COMPLETE (for SERVICE)
(E93)
A-2057-799-A ARAGON BOARD, COMPLETE (for SERVICE)
(SP, MY)
A-2057-800-A ARAGON BOARD, COMPLETE (for SERVICE)
(TH)
A-2057-801-A ARAGON BOARD, COMPLETE (for SERVICE)
(E2)
A-2072-506-A ARAGON BOARD, COMPLETE (for SERVICE)
(E51)
A-2072-508-A ARAGON BOARD, COMPLETE (for SERVICE)
(MX)
***********************
< CAPACITOR >
* C003 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C004 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C005 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C006 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C007 1-118-389-11 CERAMIC CHIP 0.022uF 10% 25V
C008 1-118-389-11 CERAMIC CHIP 0.022uF 10% 25V
C009 1-118-389-11 CERAMIC CHIP 0.022uF 10% 25V
C010 1-118-358-11 CERAMIC CHIP 100PF 1% 50V
C011 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C012 1-118-389-11 CERAMIC CHIP 0.022uF 10% 25V
C013 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C014 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C017 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C018 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C019 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C021 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C024 1-112-797-11 ELECT CHIP 470uF 20% 25V
C030 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C032 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C034 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C035 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C036 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C039 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C040 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C041 1-118-389-11 CERAMIC CHIP 0.022uF 10% 25V
C042 1-118-389-11 CERAMIC CHIP 0.022uF 10% 25V
C045 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C046 1-118-389-11 CERAMIC CHIP 0.022uF 10% 25V
C047 1-118-389-11 CERAMIC CHIP 0.022uF 10% 25V
C048 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
* C049 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C050 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C051 1-114-814-11 CERAMIC CHIP 0.33uF 10% 25V
* C052 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C053 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
C057 1-117-681-11 ELECT CHIP 100uF 20% 16V
C062 1-114-814-11 CERAMIC CHIP 0.33uF 10% 25V
C064 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
* C065 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C066 1-165-492-21 ELECT CHIP 100uF 20% 10V
C067 1-165-492-21 ELECT CHIP 100uF 20% 10V
* C068 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C071 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C072 1-165-492-21 ELECT CHIP 100uF 20% 10V
C073 1-165-492-21 ELECT CHIP 100uF 20% 10V
C074 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C075 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C078 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C079 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C080 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C081 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C083 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C084 1-117-681-11 ELECT CHIP 100uF 20% 16V
* C085 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C087 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C088 1-117-681-11 ELECT CHIP 100uF 20% 16V
* C102 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C103 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C104 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C105 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
* C106 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C107 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C109 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
* C110 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C111 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C112 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C113 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C114 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C115 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C116 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C117 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviations
E2 : 120V AC area in E model
E4 : African model
E51 : Chilean and Peruvian models
E93 : United Arab Emirates, Kuwait,
Iraq, Kenya, Tanzania and
Nigeria model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
IND : Indian model
MX : Mexican model
MY : Malaysia model
SAF : South African model
SP : Singapore model
TH : Thai model
Ver. 1.3
ARAGON

Sony MHC-V6D Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
Impedance	5 Ω
Bass reflex	-
Speaker type	3-way
RMS rated power	1440 W
Woofer diameter	250 mm
Tweeter diameter	40 mm
Number of speakers	5
Mid-range driver diameter	100 mm
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Display type	LCD
Audio (L/R) in	1
USB 2.0 ports quantity	2
Analog signal format system	NTSC, PAL
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	ENG, CHI (SIMPL), THA, CHI (TR)
Disc types supported	CD-RW, DVD-R, DVD, CD, DVD+R, DVD+R DL, CD-R, DVD+RW, DVD-RW
Audio formats supported	WMA, MP3
Power source	AC
Input voltage	120-240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Equalizer modes	Custom, Pop, Flat, Rap, Rock

Weight and Dimensions

Depth	325 mm
Width	339 mm
Height	908 mm
Weight	18000 g
Package depth	417 mm
Package width	972 mm
Package height	381 mm
Package weight	21000 g
