Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MHC-V6D
99
C1028 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C1112 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C1122 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C1125 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1126 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1157 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1160 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1163 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C1164 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C1166 1-164-315-91 CERAMIC CHIP 470PF 5% 50V
C1167 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1168 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1169 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1170 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C1171 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1172 1-118-354-11 CERAMIC CHIP 1000PF 5% 100V
C1173 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1174 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1175 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1178 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1179 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
C1180 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
C1182 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
* C1183 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
C1184 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1185 1-100-703-91 CERAMIC CHIP 10uF 10% 25V
C1186 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
C1190 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
* C1191 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
C1192 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C1193 1-118-118-91 CERAMIC CHIP 0.22uF 10% 100V
C1194 1-118-118-91 CERAMIC CHIP 0.22uF 10% 100V
C1196 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1198 1-127-813-11 ELECT (BLOCK) 3300uF 20% 71V
C1199 1-127-813-11 ELECT (BLOCK) 3300uF 20% 71V
C1202 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1209 1-164-315-91 CERAMIC CHIP 470PF 5% 50V
C1210 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1211 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1212 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1213 1-118-118-91 CERAMIC CHIP 0.22uF 10% 100V
C1214 1-118-118-91 CERAMIC CHIP 0.22uF 10% 100V
C1218 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C1219 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
C1223 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1224 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1225 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1226 1-118-354-11 CERAMIC CHIP 1000PF 5% 100V
C1227 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1228 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1229 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
C1231 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1232 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1234 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1236 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
* C1237 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
C1238 1-100-703-91 CERAMIC CHIP 10uF 10% 25V
C1239 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
* C1240 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
C1241 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C1243 1-164-315-91 CERAMIC CHIP 470PF 5% 50V
C1244 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1245 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1246 1-114-236-21 CERAMIC CHIP 22uF 10% 25V
C1247 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
C1248 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C1249 1-118-354-11 CERAMIC CHIP 1000PF 5% 100V
C1250 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1251 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1252 1-116-173-91 CERAMIC CHIP 0.0022uF 5% 50V
C1255 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1256 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
C1257 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
C1258 1-116-782-91 CERAMIC CHIP 2.2uF 10% 100V
* C1259 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
C1260 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1261 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1262 1-100-703-91 CERAMIC CHIP 10uF 10% 25V
C1263 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
C1267 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
* C1268 1-100-925-21 CERAMIC CHIP 0.0022uF 10% 250V
C1269 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C1270 1-118-118-91 CERAMIC CHIP 0.22uF 10% 100V
C1271 1-118-118-91 CERAMIC CHIP 0.22uF 10% 100V
C1272 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1275 1-127-813-11 ELECT (BLOCK) 3300uF 20% 71V
C1276 1-127-813-11 ELECT (BLOCK) 3300uF 20% 71V
C1281 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1286 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1288 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1323 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C1325 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C1329 1-100-245-21 CERAMIC CHIP 0.001uF 10% 250V
C1335 1-100-761-21 CERAMIC CHIP 0.01uF 10% 250V
C1460 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1461 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
(Suffi x-11) (See Note)
C1462 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
* C1463 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C1465 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
* C1467 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C1468 1-165-979-21 ELECT CHIP 100uF 20% 6.3V
C1471 1-117-681-11 ELECT CHIP 100uF 20% 16V
C1473 1-116-881-11 FILM 0.47uF 5% 250V
C1474 1-116-881-11 FILM 0.47uF 5% 250V
C1484 1-116-881-11 FILM 0.47uF 5% 250V
C1485 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C1488 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1490 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1493 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C1494 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1497 1-128-992-21 ELECT CHIP 47uF 20% 25V
C1498 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C1499 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C1502 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1504 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1505 1-114-599-21 ELECT CHIP 10uF 20% 35V
C1506 1-114-599-21 ELECT CHIP 10uF 20% 35V
C1508 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
C1509 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
Note: Refer to the “NEW/FORMER DISCRIMINATION OF D-AMP
AND SPEAKER LED BOARDS” on page 4 for how to distinguish
suffi x-11 of D-AMP board.
D-AMP

Sony MHC-V6D Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
Impedance	5 Ω
Bass reflex	-
Speaker type	3-way
RMS rated power	1440 W
Woofer diameter	250 mm
Tweeter diameter	40 mm
Number of speakers	5
Mid-range driver diameter	100 mm
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Display type	LCD
Audio (L/R) in	1
USB 2.0 ports quantity	2
Analog signal format system	NTSC, PAL
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	ENG, CHI (SIMPL), THA, CHI (TR)
Disc types supported	CD-RW, DVD-R, DVD, CD, DVD+R, DVD+R DL, CD-R, DVD+RW, DVD-RW
Audio formats supported	WMA, MP3
Power source	AC
Input voltage	120-240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Equalizer modes	Custom, Pop, Flat, Rap, Rock

Weight and Dimensions

Depth	325 mm
Width	339 mm
Height	908 mm
Weight	18000 g
Package depth	417 mm
Package width	972 mm
Package height	381 mm
Package weight	21000 g
