Sony MHC-V6D Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MHC-V6D
98
R728 1-218-990-81 SHORT CHIP 0
R729 1-218-929-11 METAL CHIP 10 5% 1/16W
R730 1-218-929-11 METAL CHIP 10 5% 1/16W
R731 1-218-929-11 METAL CHIP 10 5% 1/16W
R732 1-218-929-11 METAL CHIP 10 5% 1/16W
R733 1-216-864-11 SHORT CHIP 0
R734 1-218-990-81 SHORT CHIP 0
R738 1-218-929-11 METAL CHIP 10 5% 1/16W
R739 1-218-929-11 METAL CHIP 10 5% 1/16W
R740 1-218-941-81 METAL CHIP 100 5% 1/16W
R741 1-218-990-81 SHORT CHIP 0
R743 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R744 1-218-965-11 METAL CHIP 10K 5% 1/16W
R745 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R746 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R747 1-216-864-11 SHORT CHIP 0
R749 1-218-990-81 SHORT CHIP 0
R750 1-218-941-81 METAL CHIP 100 5% 1/16W
R751 1-218-941-81 METAL CHIP 100 5% 1/16W
R752 1-218-941-81 METAL CHIP 100 5% 1/16W
R753 1-218-941-81 METAL CHIP 100 5% 1/16W
R756 1-250-515-11 METAL CHIP 6.8K 1% 1/16W
R760 1-218-929-11 METAL CHIP 10 5% 1/16W
R761 1-218-929-11 METAL CHIP 10 5% 1/16W
R762 1-218-929-11 METAL CHIP 10 5% 1/16W
R763 1-216-864-11 SHORT CHIP 0
R764 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R765 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R766 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R767 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R768 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R769 1-218-990-81 SHORT CHIP 0
R770 1-218-965-11 METAL CHIP 10K 5% 1/16W
R792 1-216-864-11 SHORT CHIP 0
R794 1-216-864-11 SHORT CHIP 0
R795 1-218-929-11 METAL CHIP 10 5% 1/16W
R796 1-218-929-11 METAL CHIP 10 5% 1/16W
R797 1-218-929-11 METAL CHIP 10 5% 1/16W
R798 1-216-864-11 SHORT CHIP 0
R799 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R800 1-218-965-11 METAL CHIP 10K 5% 1/16W
R806 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R807 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R809 1-218-990-81 SHORT CHIP 0
R811 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R812 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R816 1-218-990-81 SHORT CHIP 0
R817 1-218-929-11 METAL CHIP 10 5% 1/16W
R819 1-218-929-11 METAL CHIP 10 5% 1/16W
R820 1-218-929-11 METAL CHIP 10 5% 1/16W
R821 1-218-929-11 METAL CHIP 10 5% 1/16W
R822 1-218-929-11 METAL CHIP 10 5% 1/16W
R825 1-218-990-81 SHORT CHIP 0
R851 1-218-990-81 SHORT CHIP 0
R852 1-218-990-81 SHORT CHIP 0
R853 1-218-990-81 SHORT CHIP 0
R854 1-218-990-81 SHORT CHIP 0
R855 1-218-990-81 SHORT CHIP 0
R856 1-218-990-81 SHORT CHIP 0
R857 1-216-864-11 SHORT CHIP 0
R859 1-216-864-11 SHORT CHIP 0
R905 1-218-990-81 SHORT CHIP 0
R906 1-218-973-11 METAL CHIP 47K 5% 1/16W
R907 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R908 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R910 1-218-990-81 SHORT CHIP 0
R911 1-218-985-11 METAL CHIP 470K 5% 1/16W
R912 1-218-985-11 METAL CHIP 470K 5% 1/16W
R913 1-218-975-11 METAL CHIP 68K 5% 1/16W
R914 1-218-975-11 METAL CHIP 68K 5% 1/16W
R915 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R916 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB301 1-234-370-21 RES, NETWORK 22 (1005X4)
RB302 1-234-370-21 RES, NETWORK 22 (1005X4)
RB303 1-234-370-21 RES, NETWORK 22 (1005X4)
RB304 1-234-370-21 RES, NETWORK 22 (1005X4)
RB305 1-234-370-21 RES, NETWORK 22 (1005X4)
RB306 1-234-370-21 RES, NETWORK 22 (1005X4)
RB307 1-234-370-21 RES, NETWORK 22 (1005X4)
RB308 1-234-370-21 RES, NETWORK 22 (1005X4)
RB309 1-234-370-21 RES, NETWORK 22 (1005X4)
< THERMISTOR >
TH571 1-804-949-11 THERMISTOR, NTC (SMD)
< VIBRATOR >
X101 1-814-273-11 QUARTZ CRYSTAL UNIT (32.768 kHz)
X102 1-814-767-11 QUARTZ CRYSTAL UNITS (13.333 MHz)
X103 1-814-466-11 QUARTZ CRYSTAL UNITS (12.288 MHz)
X301 1-814-023-11 QUARTS CRYSTAL UNIT (27 MHz)
X451 1-814-365-11 QUARTZ CRYSTAL UNITS (12 MHz)
************************************************************
A-1988-841-A D-AMP BOARD, COMPLETE
*********************
< CAPACITOR >
C1000 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1003 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C1004 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C1005 1-126-949-11 ELECT 220uF 20% 35V
C1006 1-126-949-11 ELECT 220uF 20% 35V
C1007 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C1008 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C1010 1-118-291-11 CERAMIC CHIP 100PF 5% 50V
C1011 1-126-949-11 ELECT 220uF 20% 35V
C1012 1-126-949-11 ELECT 220uF 20% 35V
C1013 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C1014 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C1016 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1019 1-104-666-11 ELECT 220uF 20% 25V
C1020 1-104-666-11 ELECT 220uF 20% 25V
C1021 1-137-765-21 ELECT CHIP 47uF 20% 16V
C1022 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C1023 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1024 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1025 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1026 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1027 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
ARAGON D-AMP

Sony MHC-V6D Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
Impedance	5 Ω
Bass reflex	-
Speaker type	3-way
RMS rated power	1440 W
Woofer diameter	250 mm
Tweeter diameter	40 mm
Number of speakers	5
Mid-range driver diameter	100 mm
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Display type	LCD
Audio (L/R) in	1
USB 2.0 ports quantity	2
Analog signal format system	NTSC, PAL
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	ENG, CHI (SIMPL), THA, CHI (TR)
Disc types supported	CD-RW, DVD-R, DVD, CD, DVD+R, DVD+R DL, CD-R, DVD+RW, DVD-RW
Audio formats supported	WMA, MP3
Power source	AC
Input voltage	120-240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Equalizer modes	Custom, Pop, Flat, Rap, Rock

Weight and Dimensions

Depth	325 mm
Width	339 mm
Height	908 mm
Weight	18000 g
Package depth	417 mm
Package width	972 mm
Package height	381 mm
Package weight	21000 g
