MHC-V6D
MHC-V6D
6868
• Waveforms
ARAGON Board –
0
IC101 wf (SSI3_BCKO)
1 V/DIV, 200 ns/DIV
324 ns
4.5 Vp-p
9
IC101 qf (AUDIO_CLK_OUT)
1 V/DIV, 50 ns/DIV
81 ns
4.1 Vp-p
20.8 Ps
3.4 Vp-p
qa
IC101 wh (SSI3_LRCKO)
1 V/DIV, 10 Ps/DIV
qs
IC101 wl (SSI0_BCKO)
1 V/DIV, 200 ns/DIV
324 ns
4.5 Vp-p
20.8 Ps
3.6 Vp-p
qd
IC101 e; (SSI0_LRCKO)
1 V/DIV, 10 Ps/DIV
qf
IC101 yk (RTC-X2)
500 mV/DIV, 20 Ps/DIV
30.4 Ps
1.7 Vp-p
qg
IC101 ua (XTAL)
1 V/DIV, 50 ns/DIV
75 ns
3.3 Vp-p
qh
IC101 os (AUDIO-X2)
1 V/DIV, 50 ns/DIV
81.5 ns
3.5 Vp-p
qj
IC001 2 (VBST1)
5 V/DIV, 500 ns/DIV
18.4 Vp-p
qk
IC001 qg (VBST2)
5 V/DIV, 2 Ps/DIV
6.4 Ps
18.4 Vp-p
8
IC451 8 (X2)
1 V/DIV, 50 ns/DIV
83 ns
2.9 Vp-p
1
IC301 8 (XTALO)
500 mV/DIV, 20 ns/DIV
37.2 ns
1.2 Vp-p
59 ns
4.5 Vp-p
3
IC301 <zzx (ACLK)
1 V/DIV, 50 ns/DIV
4
IC301 <zzc (ABCK)
1 V/DIV, 200 ns/DIV
352 ns
4.5 Vp-p
22.7 Ps
4 Vp-p
5
IC301 <zzm (ALRCK)
1 V/DIV, 10 Ps/DIV
6
IC301 <zxc (RFIP)
(CD play mode)
200 mV/DIV, 100 ns/DIV
1 Vp-p
2
IC301 <z// (CVBS)
(Color bar)
500 mV/DIV, 20 Ps/DIV
H
1.4 Vp-p
7
IC901 2 (VOUT)
(Color bar)
500 mV/DIV, 20 Ps/DIV
H
2.8 Vp-p
7.4 Ps
13.4 Vp-p
e;
Q2004 (BASE)
5 V/DIV, 5 Ps/DIV
wa
IC1003 6, 7
500 mV/DIV, 2 Ps/DIV
2 Ps
1.6 Vp-p
ql
IC002 2 (VBST1)
5 V/DIV, 2 Ps/DIV
5.8 Ps
19.8 Vp-p
w;
IC002 qg (VBST2)
5 V/DIV, 2 Ps/DIV
5.8 Ps
18.4 Vp-p
– D-AMP Board –
– FL Board –
