Sony MHC-V6D Service Manual

MHC-V6D
73
– FL Board –
IC2002 TC62D723FNG
VDD24
REXT
23
SOUT
22
PWMCLK
21
OUT1520
OUT14
19
OUT13
18
OUT1217
OUT1116
OUT10
15
OUT9
14
OUT8
13
GND
1
SIN
SCK
2
3
TRANS
4
OUT0
5
OUT1
OUT2
6
7
OUT3
8
OUT4
9
OUT5
OUT6
10
11
OUT7
12
OUTPUT
OPEN/SHORT
DETECTION
CIRCUIT
CONSTANT
CURRENT
OUTPUT
CIRCUIT
OUTPUT
DELAY
CIRCUIT
OUTPUT ON/OFF
SETTING DATA
REGISTER
COMPARATOR
PWM DATA
REGISTER
DATA TRANSFER
CONTROL CIRCUIT
16-bit SHIFT REGISTER
SOUT
SELECTION
CIRCUIT
COMMAND
CONTROL
CIRCUIT
PWM
COUNTER
ERROR
DETECTION
RESULT DATA
REGISTER
REFERENCE
VOLTAGE
16-bit ×2
STATE SETTING
REGISTER
TSD
CIRCUIT
POD
CIRCUIT
POR
CIRCUIT
F/F
8-bit DAC

Sony MHC-V6D Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
Impedance	5 Ω
Bass reflex	-
Speaker type	3-way
RMS rated power	1440 W
Woofer diameter	250 mm
Tweeter diameter	40 mm
Number of speakers	5
Mid-range driver diameter	100 mm
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Display type	LCD
Audio (L/R) in	1
USB 2.0 ports quantity	2
Analog signal format system	NTSC, PAL
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	ENG, CHI (SIMPL), THA, CHI (TR)
Disc types supported	CD-RW, DVD-R, DVD, CD, DVD+R, DVD+R DL, CD-R, DVD+RW, DVD-RW
Audio formats supported	WMA, MP3
Power source	AC
Input voltage	120-240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Equalizer modes	Custom, Pop, Flat, Rap, Rock

Weight and Dimensions

Depth	325 mm
Width	339 mm
Height	908 mm
Weight	18000 g
Package depth	417 mm
Package width	972 mm
Package height	381 mm
Package weight	21000 g
