MHC-V6D
74
• IC Pin Function Description
ARAGON BOARD IC101 R7S7200022CFP (SYSTEM CONTROLLER)
Pin No. Pin Name I/O Description
1 SRC-RST0 O Reset signal output to the sample rate converter “L”: reset
2 VIDEO-MUTE O Muting signal output to the video amplifi er “L”: muting on
3 CDM-UNLOAD-SW I Unloading end detection switch input terminal
4 CDM-LOAD-SW I Loading end detection switch input terminal
5 BT-RESET I Reset signal input from the Bluetooth module “L”: reset
6 DAC-MUTE O Muting signal output terminal Not used
7 VCC - Power supply terminal (+1.2V)
8 BT-ON O Power on/off control signal output terminal for Bluetooth section “H”: power on
9 VSS - Ground terminal
10 LINEOUT-SEL O Audio signal selection signal output terminal Not used
11 PVCC - Power supply terminal (+3.3V)
12 VBUS-OE O VBUS power on/off control signal output to the DC/DC converter “H”: power on
13 HUB-RESET O Reset signal output to the USB hub controller “L”: reset
14 AUDIO_CLK_OUT O Master clock signal output to the D/A converter, A/D converter and sample rate converter
15 MTK-RESET O Reset signal output to the servo/audio processor “L”: reset
16 MTK-BUSY O Busy signal output to the servo/audio processor
17 MTK-CLK I Serial data transfer clock signal input from the servo/audio processor
18 VSS - Ground terminal
19 MTK-XIFCS I Chip select signal input from the servo/audio processor
20 MTK-SDI I Serial data input from the servo/audio processor
21 VCC - Power supply terminal (+1.2V)
22 MTK-SDO O Serial data output to the servo/audio processor
23 VSS - Ground terminal
24 SSI3_BCKO O Bit clock signal output to the D/A converter
25 PVCC - Power supply terminal (+3.3V)
26 SSI3_LRCKO O L/R sampling clock signal output to the D/A converter
27 SSI3_DOUT3 O Audio signal output to the D/A converter
28 SSI3_DI I Audio signal input from the sample rate converter
29 SSI0_BCKO O Bit clock signal output to the A/D converter and D/A converter
30 SSI0_LRCKO O L/R sampling clock signal output to the A/D converter and D/A converter
31 VSS - Ground terminal
32 SSI0_DO O Audio signal (L-ch/R-ch) output to the D/A converter
33 SSI2_DO O Audio signal (subwoofer) output to the D/A converter
34 VCC - Power supply terminal (+1.2V)
35 FL-CLK O Serial data transfer clock signal output to the fl uorescent indicator tube
36 VSS - Ground terminal
37 CKIO - Not used
38 FL-LATCH O Latch signal output terminal Not used
39 PVCC - Power supply terminal (+3.3V)
40 FL-SOUT O Serial data output to the fl uorescent indicator tube
41, 42
ANALOG-ASEL,
ANALOG-BSEL
O Digital audio signal selection signal output terminal
43 DEBUG-TXD O Transmit data output terminal for the debug Not used
44 NFC-SPICLK O Serial data transfer clock signal output to the NFC module
45 POWER-KEY I Power key input terminal
46 VSS - Ground terminal
47 USB-OC I VBUS power over current detection signal input terminal
48 RGB-SOUT O Serial data output to the LED driver
49 NFC-SW O Standby control signal output to the NFC module
50 PVCC - Power supply terminal (+3.3V)
51 LINK-OUT-B O Analog audio signal selection signal output terminal
52 NFC-SEL O Data read/write control signal output to the NFC module
53 NFC-RF-DET I RF detection signal input from the NFC module
54 SSI1_DO O Not used
55 SSI1_DI I Audio (microphone) signal input from the A/D converter
56 PCONT-BTSTBY O Power on/off control signal output terminal “H”: power on
