Sony MHC-V6D Service Manual

MHC-V6D
79
Pin No. Pin Name I/O Description
72 RCLK O Clock signal output to the SD-RAM
73 to 79 RA11, RA9 to RA4 O Address signal output to the SD-RAM
80 RWE# O Write enable signal output to the SD-RAM
81 DVSS12 - Ground terminal (digital system)
82 CAS# O Column address strobe signal output to the SD-RAM
83 RAS# O Row address strobe signal output to the SD-RAM
84 DVDD33 - Power supply terminal (+3.3V) (digital system)
85, 86 BA0, BA1 O Bank address signal output to the SD-RAM
87 DVDD12 - Power supply terminal (+1.2V) (digital system)
88 to 92 RA10, RA0 to RA3 O Address signal output to the SD-RAM
93 SPDIF O SPDIF signal output terminal Not used
94 XMAMUTE O Audio muting control signal output terminal Not used
95 MFIDET I MFI detection signal input terminal Not used
96 DACVDDC - Power supply terminal (+3.3V) (for D/A converter)
97 VREF - Band-gap reference voltage terminal
98 FS - Full scale adjustment terminal
99 DACVSSC - Ground terminal (for D/A converter)
100 CVBS O Composite video signal output to the video amplifi er
101 DACVDDB - Power supply terminal (+3.3V) (for D/A converter)
102 SY/Y/G O Component video (Y) signal output terminal Not used
103 SC/CB/B O Component video (Cb/Pb) signal output terminal Not used
104 CR/R O Component video (Cr/Pr) signal output terminal Not used
105 AADVSS - Ground terminal (for A/D converter)
106 ADIN I Audio data input from the A/D converter
107, 108 NC - Not used
109 AADVDD - Power supply terminal (+3.3V) (for A/D converter)
110, 111
ADACVSS2,
ADACVSS1
- Ground terminal (for D/A converter)
112 ACLK O Master clock signal output to the A/D converter
113 ABCK O Bit clock signal output to the A/D converter and sample rate converter
114 NC - Not used
115 AVCM - Audio D/A converter reference voltage terminal
116 NC - Not used
117 ALRCK O L/R sampling clock signal output to the A/D converter and sample rate converter
118 ASDATA0 O Audio data output to the sample rate converter
119, 120
ADACVDD1,
ADACVDD2
- Power supply terminal (+3.3V) (for D/A converter)
121 AVDD12_1 - Power supply terminal (+1.2V) (analog system)
122 AGND12 - Ground terminal (analog system)
123 RFIP I AC coupled RF signal input from the optical pick-up block
124 OPDIST I Not used
125 IOPMON/OPO I Positive input to the internal operational amplifi er
126 SPFG/OP– I Negative input to the internal operational amplifi er
127 RF_A I RF main beam (C) input from the optical pick-up block
128 RF_B I RF main beam (B) input from the optical pick-up block

Sony MHC-V6D Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
Impedance	5 Ω
Bass reflex	-
Speaker type	3-way
RMS rated power	1440 W
Woofer diameter	250 mm
Tweeter diameter	40 mm
Number of speakers	5
Mid-range driver diameter	100 mm
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Display type	LCD
Audio (L/R) in	1
USB 2.0 ports quantity	2
Analog signal format system	NTSC, PAL
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	ENG, CHI (SIMPL), THA, CHI (TR)
Disc types supported	CD-RW, DVD-R, DVD, CD, DVD+R, DVD+R DL, CD-R, DVD+RW, DVD-RW
Audio formats supported	WMA, MP3
Power source	AC
Input voltage	120-240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Equalizer modes	Custom, Pop, Flat, Rap, Rock

Weight and Dimensions

Depth	325 mm
Width	339 mm
Height	908 mm
Weight	18000 g
Package depth	417 mm
Package width	972 mm
Package height	381 mm
Package weight	21000 g
