Sony MHC-V6D Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MHC-V6D
92
* C451 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C452 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C453 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C454 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C455 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C456 1-164-860-11 CERAMIC CHIP 27PF 5% 50V
C457 1-164-860-11 CERAMIC CHIP 27PF 5% 50V
* C459 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C460 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C461 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C462 1-124-779-00 ELECT CHIP 10uF 20% 16V
C463 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C464 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C465 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C466 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C467 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C468 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C571 1-100-582-21 ELECT CHIP 470uF 20% 4V
* C573 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C574 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C601 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C602 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C603 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C604 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C605 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
* C606 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C607 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C608 1-117-949-81 CERAMIC CHIP 820PF 10% 50V
C609 1-124-779-00 ELECT CHIP 10uF 20% 16V
C610 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C612 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
* C613 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C614 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
* C615 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C616 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C617 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C618 1-124-779-00 ELECT CHIP 10uF 20% 16V
C619 1-116-707-11 CERAMIC CHIP 47uF 20% 10V
C620 1-116-707-11 CERAMIC CHIP 47uF 20% 10V
C621 1-116-707-11 CERAMIC CHIP 47uF 20% 10V
C622 1-124-779-00 ELECT CHIP 10uF 20% 16V
C624 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C625 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C626 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C627 1-116-865-11 CERAMIC CHIP 10uF 10% 25V
* C628 1-116-727-11 CERAMIC CHIP 2.2uF 10% 16V
C629 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C630 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C631 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C632 1-116-707-11 CERAMIC CHIP 47uF 20% 10V
C633 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C634 1-117-949-81 CERAMIC CHIP 820PF 10% 50V
C635 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C637 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C638 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C639 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
C640 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C641 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C642 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C643 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C644 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C645 1-124-779-00 ELECT CHIP 10uF 20% 16V
C646 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C648 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C649 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C651 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C652 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C653 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C655 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
* C656 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C657 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C658 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
* C660 1-116-727-11 CERAMIC CHIP 2.2uF 10% 16V
C661 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C662 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C664 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C665 1-116-727-11 CERAMIC CHIP 2.2uF 10% 16V
C666 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C667 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C669 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C670 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C671 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C672 1-124-779-00 ELECT CHIP 10uF 20% 16V
C673 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C674 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C675 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C678 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C679 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C680 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C681 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C684 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C685 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C686 1-117-949-81 CERAMIC CHIP 820PF 10% 50V
C687 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C688 1-124-779-00 ELECT CHIP 10uF 20% 16V
C689 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C690 1-124-779-00 ELECT CHIP 10uF 20% 16V
C691 1-124-779-00 ELECT CHIP 10uF 20% 16V
C692 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C695 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C696 1-124-779-00 ELECT CHIP 10uF 20% 16V
C697 1-124-779-00 ELECT CHIP 10uF 20% 16V
C698 1-124-779-00 ELECT CHIP 10uF 20% 16V
C699 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C700 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C701 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
* C702 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C704 1-124-779-00 ELECT CHIP 10uF 20% 16V
C705 1-124-779-00 ELECT CHIP 10uF 20% 16V
C707 1-117-949-81 CERAMIC CHIP 820PF 10% 50V
C708 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C709 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C724 1-124-779-00 ELECT CHIP 10uF 20% 16V
C726 1-128-392-11 ELECT CHIP 470uF 20% 6.3V
C740 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C741 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C742 1-124-779-00 ELECT CHIP 10uF 20% 16V
C743 1-124-779-00 ELECT CHIP 10uF 20% 16V
C744 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C745 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
ARAGON

Sony MHC-V6D Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
Impedance	5 Ω
Bass reflex	-
Speaker type	3-way
RMS rated power	1440 W
Woofer diameter	250 mm
Tweeter diameter	40 mm
Number of speakers	5
Mid-range driver diameter	100 mm
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Display type	LCD
Audio (L/R) in	1
USB 2.0 ports quantity	2
Analog signal format system	NTSC, PAL
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	ENG, CHI (SIMPL), THA, CHI (TR)
Disc types supported	CD-RW, DVD-R, DVD, CD, DVD+R, DVD+R DL, CD-R, DVD+RW, DVD-RW
Audio formats supported	WMA, MP3
Power source	AC
Input voltage	120-240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Equalizer modes	Custom, Pop, Flat, Rap, Rock

Weight and Dimensions

Depth	325 mm
Width	339 mm
Height	908 mm
Weight	18000 g
Package depth	417 mm
Package width	972 mm
Package height	381 mm
Package weight	21000 g
