Sony MHC-V6D Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MHC-V6D
93
C746 1-117-949-81 CERAMIC CHIP 820PF 10% 50V
C747 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C748 1-124-779-00 ELECT CHIP 10uF 20% 16V
C749 1-124-779-00 ELECT CHIP 10uF 20% 16V
C751 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C752 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C753 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C754 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C756 1-124-779-00 ELECT CHIP 10uF 20% 16V
* C757 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C758 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
* C759 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C766 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C767 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
C904 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C906 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C913 1-165-708-11 ELECT CHIP 47uF 20% 6.3V
* C914 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C917 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
< CONNECTOR >
CN001 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN102 1-820-825-81 CONNECTOR, FFC/FPC (LIF) 10P
CN105 1-820-384-31 CONNECTOR, FFC/FPC (LIF) 8P
CN107 1-778-384-51 CONNECTOR, FFC/FPC 16P
CN109 1-820-121-41 CONNECTOR, FFC/FPC 23P
CN112 1-820-117-41 CONNECTOR, FFC/FPC 19P
CN302 1-843-557-11 FFC ST CONNECTOR (NON-ZIF) 24P
CN303 1-794-362-51 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 5P
CN304 1-573-806-21 PIN, CONNECTOR (1.5 mm) (SMD) 6P
CN401 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN451 1-770-468-21 PIN, CONNECTOR (PC BOARD) 10P
CN601 1-764-250-21 PIN, CONNECTOR (PC BOARD) 4P
CN851 1-820-112-41 CONNECTOR, FFC/FPC 9P
CN901 1-770-469-21 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D003 6-500-400-01 DIODE BAV99-215
D005 6-500-400-01 DIODE BAV99-215
D102 6-502-961-01 DIODE DA2J10100L
D401 8-719-069-29 DIODE RB520S-30FJTE61
D402 8-719-069-29 DIODE RB520S-30FJTE61
D571 6-502-961-01 DIODE DA2J10100L
D572 6-502-961-01 DIODE DA2J10100L
< FERRITE BEAD >
FB003 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB004 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB005 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB006 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB007 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB008 1-469-670-21 FERRITE, EMI (SMD) (2012)
FB101 1-481-515-11 BEAD, FERRITE (1608)
< IC >
IC001 (Not supplied) IC TPS542941PWPR (See Note)
IC002 (Not supplied) IC TPS542941PWPR (See Note)
IC004 6-715-078-01 IC KIA7809AF/API
IC006 6-717-138-01 IC KIA7805AF-RTF/PW
IC101 6-721-336-01 IC R7S7200022CFP
IC102 6-707-866-01 IC TC74VHC126FT (EK)
IC103 6-719-856-01 IC BU4229F-TR
IC105 (Not supplied) IC MFI337S3959 (See Note)
IC106 (Not supplied) IC W25Q32FVSSIG (See Note)
IC301 (Not supplied) IC CXD9990R (See Note)
IC302 (Not supplied) IC W25Q32BVSSIG-R (See Note)
IC303 6-712-033-01 IC MM1701CHBE
IC304 6-714-351-01 IC R1EX24016ASAS0A
IC305 6-717-694-01 IC BU33TD3WG-TR
IC306 6-720-220-01 IC M12L64164A-7TG2Y
IC401 6-720-195-01 IC AM5890S
* IC451 6-721-151-01 IC GL850G-OGY33
IC452 6-718-580-01 IC BA2903FV-E2
IC601 8-759-909-71 IC BA4558F
IC602 8-759-596-39 IC SN74LV4052APWR
IC603 8-759-909-71 IC BA4558F
IC604 6-705-973-01 IC PCM1754DBQR
IC605 8-759-596-39 IC SN74LV4052APWR
IC606 6-710-554-01 IC PCM1808PWR
IC607 8-759-680-48 IC TC7WH157FK
IC609 6-710-554-01 IC PCM1808PWR
IC610 6-707-800-01 IC SRC4182
IC611 6-705-973-01 IC PCM1754DBQR
IC612 8-759-909-71 IC BA4558F
IC615 6-705-973-01 IC PCM1754DBQR
IC616 8-759-909-71 IC BA4558F
IC901 6-720-187-01 IC NJM41031F1 (TE2)
< JACK >
J601 1-794-981-11 JACK, PIN 4P (AUDIO OUT/PARTY CHAIN OUT,
AUDIO IN/PARTY CHAIN IN)
< JUMPER RESISTOR >
JC007 1-216-295-91 SHORT CHIP 0
JC008 1-216-295-91 SHORT CHIP 0
JC009 1-216-295-91 SHORT CHIP 0
< COIL >
L001 1-460-359-11 COIL, CHOKE 4.7uH
L002 1-460-358-11 COIL, CHOKE 2.2uH
L006 1-457-439-11 CHOKE COIL (SMD) 4.7uH
L007 1-460-358-11 COIL, CHOKE 2.2uH
< TRANSISTOR >
Q001 6-550-987-01 TRANSISTOR RN1911
Q002 6-550-363-01 TRANSISTOR 2SB1690KT146
Q003 8-729-054-16 TRANSISTOR KRC402-RTK
Q004 6-551-728-01 TRANSISTOR 2SB1710TL
Q005 6-550-363-01 TRANSISTOR 2SB1690KT146
Q006 8-729-054-16 TRANSISTOR KRC402-RTK
Q007 6-551-728-01 TRANSISTOR 2SB1710TL
Q008 6-551-728-01 TRANSISTOR 2SB1710TL
Q009 8-729-054-16 TRANSISTOR KRC402-RTK
Q011 6-551-728-01 TRANSISTOR 2SB1710TL
Q012 8-729-427-72 TRANSISTOR XP4501
Q017 6-552-922-01 TRANSISTOR LTA014EUBFS8TL
Q018 8-729-054-16 TRANSISTOR KRC402-RTK
Q103 6-551-728-01 TRANSISTOR 2SB1710TL
Q104 8-729-054-16 TRANSISTOR KRC402-RTK
Q107 8-729-054-16 TRANSISTOR KRC402-RTK
Note: IC001, IC002, IC105, IC106, IC301 and IC302 on the ARAGON
board cannot replace with single. When these parts are damaged,
replace the complete mounted board.
ARAGON

Sony MHC-V6D Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
Impedance	5 Ω
Bass reflex	-
Speaker type	3-way
RMS rated power	1440 W
Woofer diameter	250 mm
Tweeter diameter	40 mm
Number of speakers	5
Mid-range driver diameter	100 mm
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Display type	LCD
Audio (L/R) in	1
USB 2.0 ports quantity	2
Analog signal format system	NTSC, PAL
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	ENG, CHI (SIMPL), THA, CHI (TR)
Disc types supported	CD-RW, DVD-R, DVD, CD, DVD+R, DVD+R DL, CD-R, DVD+RW, DVD-RW
Audio formats supported	WMA, MP3
Power source	AC
Input voltage	120-240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Equalizer modes	Custom, Pop, Flat, Rap, Rock

Weight and Dimensions

Depth	325 mm
Width	339 mm
Height	908 mm
Weight	18000 g
Package depth	417 mm
Package width	972 mm
Package height	381 mm
Package weight	21000 g
