Sony MHC-V6D Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MHC-V6D
94
Q109 6-552-922-01 TRANSISTOR LTA014EUBFS8TL
Q401 6-551-120-01 TRANSISTOR 2SA2119K
Q402 6-551-120-01 TRANSISTOR 2SA2119K
Q571 8-729-054-16 TRANSISTOR KRC402-RTK
Q572 6-551-728-01 TRANSISTOR 2SB1710TL
Q574 6-552-967-01 FET RHK005N03T146
Q575 6-552-922-01 TRANSISTOR LTA014EUBFS8TL
Q576 8-729-054-16 TRANSISTOR KRC402-RTK
* Q602 6-551-959-01 TRANSISTOR IMX25T110
Q603 6-551-039-01 TRANSISTOR RN4902 (T5RSONY, D, F)
Q604 6-550-978-01 TRANSISTOR RN1902
Q605 8-729-427-72 TRANSISTOR XP4501
Q606 6-552-922-01 TRANSISTOR LTA014EUBFS8TL
Q607 6-551-039-01 TRANSISTOR RN4902 (T5RSONY, D, F)
Q611 6-550-978-01 TRANSISTOR RN1902
< RESISTOR >
R002 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R003 1-208-923-11 METAL CHIP 33K 0.5% 1/16W
R006 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R007 1-218-931-11 METAL CHIP 15 5% 1/16W
R008 1-218-931-11 METAL CHIP 15 5% 1/16W
R009 1-216-864-11 SHORT CHIP 0
R012 1-216-296-11 SHORT CHIP 0
R013 1-216-864-11 SHORT CHIP 0
R014 1-216-864-11 SHORT CHIP 0
R015 1-216-864-11 SHORT CHIP 0
R016 1-216-864-11 SHORT CHIP 0
R017 1-216-864-11 SHORT CHIP 0
R018 1-216-864-11 SHORT CHIP 0
R021 1-218-931-11 METAL CHIP 15 5% 1/16W
R022 1-218-931-11 METAL CHIP 15 5% 1/16W
R023 1-218-974-11 METAL CHIP 56K 5% 1/16W
R024 1-208-895-81 METAL CHIP 2.2K 0.5% 1/16W
R028 1-218-965-11 METAL CHIP 10K 5% 1/16W
R029 1-216-843-11 METAL CHIP 68K 5% 1/10W
R030 1-218-843-11 METAL CHIP 680 0.5% 1/10W
R031 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R033 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R034 1-216-813-11 METAL CHIP 220 5% 1/10W
R035 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R037 1-218-965-11 METAL CHIP 10K 5% 1/16W
R039 1-218-965-11 METAL CHIP 10K 5% 1/16W
R040 1-216-817-11 METAL CHIP 470 5% 1/10W
R041 1-208-709-11 METAL CHIP 12K 0.5% 1/16W
R043 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R047 1-216-864-11 SHORT CHIP 0
R048 1-216-864-11 SHORT CHIP 0
R051 1-216-295-91 SHORT CHIP 0
R052 1-216-295-91 SHORT CHIP 0
R053 1-216-864-11 SHORT CHIP 0
R054 1-216-864-11 SHORT CHIP 0
R058 1-216-864-11 SHORT CHIP 0
R059 1-218-974-11 METAL CHIP 56K 5% 1/16W
R061 1-218-965-11 METAL CHIP 10K 5% 1/16W
R062 1-218-951-11 METAL CHIP 680 5% 1/16W
R063 1-216-864-11 SHORT CHIP 0
R064 1-216-843-11 METAL CHIP 68K 5% 1/10W
R065 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R066 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R067 1-218-965-11 METAL CHIP 10K 5% 1/16W
R068 1-218-965-11 METAL CHIP 10K 5% 1/16W
R074 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R099 1-218-965-11 METAL CHIP 10K 5% 1/16W
R100 1-218-937-11 METAL CHIP 47 5% 1/16W
R101 1-218-965-11 METAL CHIP 10K 5% 1/16W
R102 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
(MX)
R102 1-218-965-11 METAL CHIP 10K 5% 1/16W
(E2, E51)
R102 1-218-973-11 METAL CHIP 47K 5% 1/16W
(E4, E93, SAF, IND)
R103 1-218-941-81 METAL CHIP 100 5% 1/16W
R104 1-218-965-11 METAL CHIP 10K 5% 1/16W
R105 1-218-965-11 METAL CHIP 10K 5% 1/16W
R106 1-218-965-11 METAL CHIP 10K 5% 1/16W
R107 1-218-965-11 METAL CHIP 10K 5% 1/16W
R108 1-218-965-11 METAL CHIP 10K 5% 1/16W
R109 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R110 1-218-977-11 METAL CHIP 100K 5% 1/16W
R111 1-218-977-11 METAL CHIP 100K 5% 1/16W
R112 1-218-977-11 METAL CHIP 100K 5% 1/16W
R113 1-216-864-11 SHORT CHIP 0
R114 1-216-864-11 SHORT CHIP 0
R115 1-218-953-11 METAL CHIP 1K 5% 1/16W
R116 1-218-973-11 METAL CHIP 47K 5% 1/16W
R117 1-218-965-11 METAL CHIP 10K 5% 1/16W
R119 1-218-990-81 SHORT CHIP 0
R120 1-218-973-11 METAL CHIP 47K 5% 1/16W
R122 1-218-990-81 SHORT CHIP 0
R123 1-218-965-11 METAL CHIP 10K 5% 1/16W
R125 1-218-973-11 METAL CHIP 47K 5% 1/16W
R126 1-218-990-81 SHORT CHIP 0
R127 1-218-965-11 METAL CHIP 10K 5% 1/16W
R128 1-218-953-11 METAL CHIP 1K 5% 1/16W
R129 1-218-941-81 METAL CHIP 100 5% 1/16W
R130 1-218-941-81 METAL CHIP 100 5% 1/16W
R131 1-218-941-81 METAL CHIP 100 5% 1/16W
R132 1-218-937-11 METAL CHIP 47 5% 1/16W
R133 1-218-937-11 METAL CHIP 47 5% 1/16W
R134 1-218-937-11 METAL CHIP 47 5% 1/16W
R135 1-218-937-11 METAL CHIP 47 5% 1/16W
R136 1-218-969-11 METAL CHIP 22K 5% 1/16W
R139 1-218-969-11 METAL CHIP 22K 5% 1/16W
R140 1-218-969-11 METAL CHIP 22K 5% 1/16W
R142 1-216-864-11 SHORT CHIP 0
R143 1-218-969-11 METAL CHIP 22K 5% 1/16W
R144 1-218-967-11 METAL CHIP 15K 5% 1/16W
R145 1-218-967-11 METAL CHIP 15K 5% 1/16W
R146 1-218-965-11 METAL CHIP 10K 5% 1/16W
R151 1-216-864-11 SHORT CHIP 0
R153 1-218-965-11 METAL CHIP 10K 5% 1/16W
R154 1-218-941-81 METAL CHIP 100 5% 1/16W
R155 1-218-941-81 METAL CHIP 100 5% 1/16W
R156 1-218-941-81 METAL CHIP 100 5% 1/16W
R157 1-218-953-11 METAL CHIP 1K 5% 1/16W
R158 1-218-949-11 METAL CHIP 470 5% 1/16W
R159 1-218-949-11 METAL CHIP 470 5% 1/16W
R160 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
(IND)
Ver. 1.3
ARAGON

Sony MHC-V6D Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
Impedance	5 Ω
Bass reflex	-
Speaker type	3-way
RMS rated power	1440 W
Woofer diameter	250 mm
Tweeter diameter	40 mm
Number of speakers	5
Mid-range driver diameter	100 mm
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Display type	LCD
Audio (L/R) in	1
USB 2.0 ports quantity	2
Analog signal format system	NTSC, PAL
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	ENG, CHI (SIMPL), THA, CHI (TR)
Disc types supported	CD-RW, DVD-R, DVD, CD, DVD+R, DVD+R DL, CD-R, DVD+RW, DVD-RW
Audio formats supported	WMA, MP3
Power source	AC
Input voltage	120-240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Equalizer modes	Custom, Pop, Flat, Rap, Rock

Weight and Dimensions

Depth	325 mm
Width	339 mm
Height	908 mm
Weight	18000 g
Package depth	417 mm
Package width	972 mm
Package height	381 mm
Package weight	21000 g
