115Super Mix Settings
Chapter 3 Signal Selection and Transitions
Super Mix Settings
You can set the output levels of the current and new video signals at the mid-
point of the transition, in the range 0 to 100%.
Note
This transition type is not available for an independent key transition.
1
In the M/E or PGM/PST menu, select first VF7 ‘Misc,’ then HF1
‘Transition.’
The Transition menu appears.
2
Select [Super Mix] in the <Transition Type> group.
3
Turn the knobs to adjust the output levels.
Knob Parameter Adjustment Setting values
2 A Gain Background A output level 0.00 to 100.00%
3 B Gain Background B output level 0.00 to 100.00%
