160
Key Setting Operations Using Menus
Chapter 4 Keys
The Matte Adjust menu appears.
2
Select [Mix Color] in the <Fill Matte> group.
3
Adjust the following parameters.
You can change this pattern by pressing [Pattern Select] to open the menu
for key wipe pattern selection (Pattern Select menu), and make
adjustments by pressing [Pattern Adjust] to open the menu for pattern
adjustment (Wipe Adjust menu).
4
In the Type menu, adjust color 1 and color 2.
To adjust color 1, select [Color1], and to adjust color 2, select [Color2],
then adjust the following parameters.
5
To interchange color 1 and color 2, press the [Color Invert] button, turning
it on.
Key Edge Modifications
Note
For key 3 and key 4, it is not possible to use edge modifiers.
To modify the key edge of key 1 on the M/E-1 bank, use the following
procedure.
1
In the M/E-1 >Key1 menu, select HF2 ‘Edge.’
The Edge menu appears.
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Softness of the edge of the
pattern
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
To Next Page
