Resizer DME Wipe Setting
Chapter 6 DME Wipes
Resizer DME Wipe Setting
A DME wipe is only possible when using the resizer or a switcher with
incorporated DME.
Notes
• It is not possible to use a resizer DME wipe for key 3 or key 4.
• When the screen aspect ratio is 4:3 in HD format, when the resizer DME
wipe is used to shrink a video image, this is applied to the 16:9 screen
including the added video on the left and right sides. Use the crop function
as required to extract the 4:3 image.
DME wipe patterns available for resizer DME wipe
You can use the following patterns of the DME wipe pattern one-channel mode
that can be used in a resizer DME wipe. (7000-series numbers)
• Slide (pattern numbers: 7001 to 7008)
• Squeeze (pattern numbers: 7021 to 7031)
• frame in-out (pattern numbers: 7201 to 7208, 7221 to 7224)
Relation between DME wipes and other effects
The following relations hold between a resizer DME wipe and other effects.
Relation to processed keys
It is not possible to select a resizer DME wipe for a key with processed key
enabled.
Relation to resizer
It is not possible to use a resizer DME wipe for a key with resizer enabled.
Making resizer DME wipe settings
1
In the <Pattern Select> group of the Key1 DME Wipe Adjust menu, press
[1ch].
The 1ch Pattern Select menu appears.
2
Select [Resizer Slide/Squeeze] or [Resizer Frame I/O].
The patterns of the selected group appear.
The wipe patterns that can be used for a resizer DME wipe are as follows.
• Slide (pattern numbers: 7001 to 7008)
