211Basic Procedure for Wipe Settings
Chapter 5 Wipes
The Main Modify menu appears.
2
Press [Aspect], turning it on.
3
Set the following parameter.
Setting the wipe pattern replication (Multi)
The same pattern can be repeated horizontally and vertically or both, up to 63
times. You can also change the orientation of alternate copies, or change the
position.
• The parameter H Multi determines the number of pattern replications
horizontally, and the parameter V Multi determines the number of pattern
replications vertically.
You can use the “Invert Type” parameter to select from the following four
types of replication patterns.
1: All replications in the same orientation
2: Even-numbered rows staggered
3: Even-numbered columns and rows inverted
4: Even-numbered columns and rows inverted, and even-numbered rows
staggered
1
In the M/E-1 >Wipe menu, select HF5 ‘Main Modify.’
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio
–100.00 to +100.00
“Multi” off
“Multi” on
1234
