233Basic Procedure for DME Wipe Settings
Chapter 6 DME Wipes
• User Program: user programmable DME
For details of DME wipe patterns, see “Types of DME Wipe Pattern”
(page 222) and “DME Wipe Pattern List” (page 363).
The patterns from the selected pattern group appear on the screen.
3
Press the button to select the desired pattern.
Note
For a key transition, the picture-in-picture cannot be used.
Adjusting DME wipe pattern parameters
Of the DME wipe patterns, the following have parameters that can be adjusted.
When Brick (for two channels) is selected (pattern numbers 2801
to 2804, 2811 to 2814)
a) The horizontal center position of the video pasted on Side V. At –100.00 the center is at the left
edge of the screen, and at +100.00 the center is at the right edge of the screen.
b) The vertical center position of the video pasted on Side V. At –100.00 the center is at the bottom
edge of the screen, and at +100.00 the center is at the top edge of the screen.
When Frame in-out (for two channels) is selected
• Pattern numbers 2851 to 2854
• Pattern numbers 2861 to 2864
Knob Parameter Adjustment Setting values
1 Side V Size X Horizontal magnification 0.01 to 8.00
2 Side V Size Y Vertical magnification 0.01 to 8.00
3 Height Height of brick 0.01 to 100.00
4 Center X Horizontal center position
–100.00 to +100.00
a)
5 Center Y Vertical center position
–100.00 to +100.00
b)
Knob Parameter Adjustment Setting values
5 Delay Timing for video selected on
a utility bus to appear on the
screen
–100.00 to +100.00
Knob Parameter Adjustment Setting values
1 Rot X Rotation about the Y axis
(horizontal direction)
–100.00 to +100.00
2 Rot Y Rotation about the X axis
(vertical direction)
–100.00 to +100.00
3 Rot Z Rotation about the Z axis –100.00 to +100.00
