235Basic Procedure for DME Wipe Settings
Chapter 6 DME Wipes
For a pattern in one-channel mode: press [1st Ch], turning it on.
For a pattern in two-channel mode: from the <Ch Select> group, select
the corresponding channel. You can select more than one channel at
the same time.
3
In the <Edge> group, select the edge type.
Border: border
Soft Border: soft border
4
Set the parameters according to the selection in step 3.
• When border is selected
• When soft border is selected
Display indications when multiple channels are selected at the same
time
The indications on the knobs show the settings of the lowest-numbered
channel. When you turn the knobs to adjust the settings, this changes the
settings on the other channels by the same amount.
Setting the DME wipe position (Positioner)
1
In the M/E-1 >DME Wipe menu, select HF5 ‘Modify.’
The Modify menu appears.
2
Depending on whether the DME wipe pattern is in one-channel mode or
two-channel mode, proceed as follows.
For a pattern in one-channel mode: press [1st Ch], turning it on.
Knob Parameter Adjustment Setting values
1 Width Border width 0.00 to 100.00
3 Luminance Luminance 0.00 to 100.00
4 Saturation Saturation 0.00 to 100.00
5 Hue Hue 359.99 to 0.00
Knob Parameter Adjustment Setting values
1 Width Border width 0.00 to 100.00
2 Inner Soft Border inner softness 0.00 to 100.00
3 Luminance Luminance 0.00 to 100.00
4 Saturation Saturation 0.00 to 100.00
5 Hue Hue 359.99 to 0.00
